MyPBX U100/U200 Administrator Guide
72/195
Ring: Start when a ring is received (Caller ID Signaling: Bell_USA, DTMF).
Polarity: Start when a polarity reversal is started (Caller ID Signaling: V23_UK,
V23_JP, DTMF).
Before Ring: Start before a ring is received (Caller ID Signaling: DTMF).
·Caller ID Signaling
This option defines the type of Caller ID signaling to use. It can be set to one of
the following:
Bell: bell202 as used in the United States
v23_UK: suitable in the UK
v23_Japan: suitable in Japan
v23-Japan pure: suitable in Japan
DTMF: suitable in Denmark, Sweden, and Holland
.Caller ID Detection
For FXO trunks, this option forces MyPBX to clarify Caller ID incoming calls
GSM/UMTS Trunk
GSM/UMTS trunks are supported in MyPBX Standard V7 if you have got the
GSM/UMTS module and SIM cards installed. One GSM/UMTS trunk supports
only one SIM card for one concurrent call.
Figure 6-24
Click edit to configure more details.
Figure 6-25
Trunk Name
A unique label used to identify this trunk when listed in outbound rules,
incoming rules, etc. E.g. “GSM/UMTS9”.
