USB Function
SD Sets or queries the source value
Command = SDm<CRLF> -> Answer = SDm<CRLF>
Command = SD?<CRLF> -> Return = SDm<CRLF>
Parameters
m = Source value
Source range m
(DCV) 100 mV: -110.000 to 110.000
1-5 V: 0.0000 to 6.0000
1-5 V√: 0.0000 to 6.0000
5 V: -6.0000 to 6.0000
30 V: -33.000 to 33.000
(DCA) 20mA: -24.000 to 24.000
4-20mA: 0.000 to 24.000
4-20mA√: 0.000 to 24.000
20mA Simulate: 0.000 to 24.000
(Ω) 400Ω: 0.00 to 440.00
4000Ω: 0.0 to 4400.0
(FREQ) 500Hz
1
: 1.00 to 550.00
5000Hz
1
: 1.0 to 5500.0
50kHz
1
: 0.001 to 50.000
(PULSE) CPM: 1.0 to 1100.0
PULSE DCV
2
: 0 to 15.0000
PULSE Cycle
3
: 0 (cont), 1 to 99999
(TC) K: -200.0 to 1372.0
E: -250.0 to 1000.0
J: -210.0 to 1200.0
T: -250.0 to 400.0
N: -200.0 to 1300.0
L: -200.0 to 900.0
U: -200.0 to 600.0
R: -20.0 to 1767.0
S: -20.0 to 1768.0
B: 600.0 to 1820.0
C: 0.0 to 2315.0
XK: -200.0 to 800.0
A: 0.0 to 2500.0
D (W3Re/W25Re): 0.0 to 2315.0
G (W/W26Re): 100.0 to 2315.0
Platinel II: 0.0 to 1395.0
PR20-40: 0.0 to 1888.0
(RTD) PT100 (3850): -200.0 to 630.0
PT100 JIS (3851): -200.0 to 800.0
PT100 former JIS (3916): -200.0 to 510.0
PT100 (3926): -200.0 to 630.0
PT200: -200.0 to 630.0
PT500: -200.0 to 630.0
PT1000: -200.0 to 630.0
Cu10: -100.0 to 260.0
Ni120: -80.0 to 260.0
PT50: -200.0 to 630.0
PT50G: -200.0 to 800.0
PT100G: -200.0 to 630.0
Cu50M: -180.0 to 200.0
Cu100M: -180.0 to 200.0
1 Can be set when the PULSE source display is set to frequency (PU0)
2 Can be set when the PULSE source display is set to amplitude (PU1)
3 Can be set when the PULSE source display is set to pulse count (PU2)
7.4 Commands
