IM CA71-E
xi
1
2
3
4
5
6
7
8
9
10
11
12
13
App
5. Measurement ....................................5-1
5.1 Connecting Cables to Terminals.......................5-2
5.2 Measuring 300 V AC-range Voltage,
DC Voltage, AC Voltage or DC Current .................5-4
5.2.1 Measuring 300 V AC-range Voltage...............5-4
5.2.2 Measuring DC or AC Voltage . . . . . . . . . . . . . . . . . . . .5-5
5.2.3 Measuring DC Current . . . . . . . . . . . . . . . . . . . . . . . . .5-5
5.3 Measuring Resistance or RTD (CA71 only) Signal.........5-6
5.4 Measuring Temperature with
Thermocouple (TC) - CA71 only -......................5-7
5.5 Measuring Frequency or Pulses.......................5-8
5.5.1 Operating the Calibrator for Frequency
Measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-8
5.5.2 Operating the Calibrator for Measuring Number of
Pulses .....................................5-8
6. Memory Functions ...............................6-1
6.1 Saving Data into Memory ............................6-2
6.1.1 Saving Data in the Order of Memory Numbers ......6-2
6.1.2 Saving Data by Selecting Desired Memory Number ..6-4
6.1.3 Overwriting Data in Memory.....................6-4
6.2 Reading Data from Memory . . . . . . . . . . . . . . . . . . . . . . . . . .6-5
6.3 Clearing Data in Memory ............................6-6
6.3.1 Clearing Data by Selecting Desired
Memory Number..............................6-6
6.3.2 Clearing All In-Memory Data Globally..............6-7
6.4 Sending Out Data from Memory
- CA71 only -......................................6-7
7. Functions Provided by DIP Switch ..................7-1
7.1 Sweep Function ...................................7-2
7.2 Auto Step Function.................................7-4
7.3 Selecting the INT RJ Function ........................7-6
7.4 Selecting the IPTS-68 Function .......................7-7
7.5 Switch Not Used...................................7-7
7.6 Temp Switch ......................................7-7
7.7 Selecting the Contact In Function
(Contact Input for Pulse Measurement) .................7-7
Contents
To Next Page
