5.3 Measuring Resistance or RTD (CA71 only)
Signal
Step 1: Using the function selector switch, select
.
Step 2: Using the
key, select the range.
Pressing the key cycles through the 400 Ω,
Pt100 and JPt100 options.
TIP
• If you select the 400 Ω RTD range of the SOURCE mode at the same time,
the RTD selected on the SOURCE mode side precedes the one selected
on the MEASURE mode side. Thus, you cannot select any RTD for the
range of the MEASURE mode. (CA71 only)
• To carry out measurement based on three-wire connection, use the 3WIRE
terminal.
5.3
Measuring Resistance or RTD (CA71 only) Signal
