Functions Provided by DIP Switch
7
7.4 Selecting the IPTS-68 Function
By placing switch 4 (IPTS-68 switch) in the ON (right-side) position,
you can select the IPTS-68 temperature scale when you choose the
type-K, E, J, T, N, R, S or B thermocouple or the Pt100 RTD.
Placing the switch in the OFF position results in the selection of the
ITS-90 temperature scale.
TIP
When you have selected a type of thermocouple or RTD, the LCD shows
IPTS-68.
7.5 Switch Not Used
Although switch 5 (No Use switch) of the DIP has no effect on
calibrator operation, the switch should be placed in the OFF
(left-side) position.
7.6 Temp Switch
Check that the switch should be placed in the OFF position.
7.7 Selecting the Contact In Function
(Contact Input for Pulse Measurement)
By placing switch 7 (Contact In switch) in the ON (right-side) position,
you can measure transistor contact on-off signals.
If you select the contact input function, the
(contact) symbol
appears on the LCD.
By placing the switch in the OFF position, you can measure normal
pulse.
