3-4
IM CA71-E
Step 1: Remove the lead cables and AC adapter and turn off the
calibrator before you begin installing batteries.
Step 2: Remove the battery holder cover by sliding it in the direction
indicated by → OPEN.
Step 3: Install four AA-size (LR6) alkaline batteries in the battery
holder with their positive and negative electrodes positioned
correctly as indicated on the holder.
Step 4: After replacement, reattach the battery holder cover.
Indication of Battery Level
(Remaining Battery Power Indicator)
The battery replacement indicator shows the battery level in three
steps according to the measured voltage of the batteries.
(Lit constantly): The battery level is normal.
(Lit constantly): The battery level is below 50% full,
but still allows for normal operation.
(ashing): replace the batteries.
3. Before Starting Source/Measurement
