Functions Provided by DIP Switch
7
Step 8: Using each pair of
and keys, set the value of the
denominator m and the starting setpoint of the enumerator n.
(See Section 4.6, "Divided Output Function (n/m), for further
details.) The starting setpoint is the minimum of the variable
n for auto step operation.
Step 9: Pressing the
key initiates the automatic stepping of the
divided output (n/m), as described below.
Assuming the starting value of the variable n is 1, the output
cyclically changes with the variable n as n changes in the
following manner.
n = 1
→
2
→
3
→
· · · (m – 1)
→
m
→
(m – 1)
→
· · ·
→
2
→
1
→
2
→
3
→
· · ·
Step 10: To quit the auto step function, turn off the calibrator by
pressing the
key. Place switch 1 back in the OFF
(left-side) position. Note that disabling the divided output
mode (n/m) before placing switch 1 back in the OFF position
enters sweep mode.
TIP
• Pressing the key to change to the SOURCE OFF state pauses the
auto step operation.
• To execute the auto step function again, press the
key.
The auto step operation resumes from the value of n shown on the LCD.
