13
IM 04L05A01-02E
Turning ON/OFF the Power Switch
Turning ON the Power
1.
Open the front cover by pressing down on the knob that is located in the center
of the upper section of the cover and pulling forward.
2.
Turn ON the power switch.
3.
Close the front cover.
After performing a self-test for a few seconds, the operation screen appears.
DX100P DX200P
Knob
Knob
Front cover
Power switch
Turning OFF the power
1.
Open the front cover.
2.
Turn OFF the power switch.
3.
Close the front cover.
Inserting/Removing the External Storage Medium
Inserting the External Storage Medium
1.
Open the front cover.
2.
Insert the external storage medium into the drive and press it until it clicks into
place.
Zip disk
Eject button*
Eject button*
ATA flash memory card
* Used to remove the storage medium.
3.
Close the front cover. Closing the front cover causes the DXP to detect the
existence of an external storage medium in the drive. If the storage medium is
detected, an external storage medium icon is displayed in the status display
section of the screen.
DX200PDX100P
Status display section
External storage medium icon
Removing the External Storage Medium
ATA flash memory cards can be removed from the drive regardless of whether the DXP
is turned ON or OFF. Zip disks cannot be removed when the DXP is turned OFF.
1.
Check that the external storage medium is not being accessed.
2.
Open the front cover.
3.
Press the eject button (above figure) and remove the external storage medium.
4.
Close the front cover. The external storage medium icon in the status display
section disappears.
To Next Page
