26 IM 04L05A01-02E
DX100P DX200P
AUX, Time zone
AUX, Time zone
Tag/Channel No. display
Channel: Displays channel numbers.
Tag: Displays tags. The tags are
set in the engineering mode (see page
29).
Logging Out (Exiting System Mode)
1. If an item setting screen is displayed, press ESC to return to the system mode
menu.
2. Press the Next #/# soft key to show the menu with [End].
3. Press the End soft key.
A confirmation window opens.
DX200PDX100P
4. Select [Yes] using the arrow keys and press DISP/ENTER.
The system mode ends and you are logged out from the DXP.
DX200PDX100P
Setting the DXP by the Administrator
