Page #147 background imageLoading...
Page #147 background image
5-114
IM 710105-17E
:HISTory[:SEARch]:NUMBer<x>:PARamete
r:LIMit
Function Sets or queries the specified waveform
parameter’s upper and lower limits for parameter
searching.
Syntax
:HISTory[:SEARch]:NUMBer<x>:
PARameter:LIMit {<NRf>}
:HISTory[:SEARch]:NUMBer<x>:
PARameter:LIMit?
<x> = 1 to 4
<NRf> = See the DLM2000 Features Guide for
this information.
Example
:HISTORY:SEARCH:NUMBER1:PARAMETER:LIM
IT 0,1
:HISTORY:SEARCH:NUMBER1:PARAMETER:LIM
IT?
-> :HISTORY:SEARCH:NUMBER1:PARAMETER:
LIMIT 1.000E+00,0.000E+00
:HISTory[:SEARch]:NUMBer<x>:PARamete
r:TRACe
Function Sets or queries the specified waveform
parameter’s source waveform for parameter
searching.
Syntax
:HISTory[:SEARch]:NUMBer<x>:
PARameter:TRACe {<NRf>|BIT<x>|FFT<x>|
MATH<x>|XY<x>}
:HISTory[:SEARch]:NUMBer<x>:
PARameter:TRACe?
<x> = 1 to 4
<NRf> = 1 to 4 (1 or 2 for 2-channel models)
<x> of BIT<x> = 1 to 8
<x> of FFT<x> = 1 or 2 (1 only for 2-channel
models)
<x> of MATH<x> = 1 or 2 (1 only for 2-channel
models)
<x> of XY<x> = 1 or 2 (1 only for 2-channel
models)
Example
:HISTORY:SEARCH:NUMBER1:PARAMETER:TRA
CE 1
:HISTORY:SEARCH:NUMBER1:PARAMETER:TRA
CE?
-> :HISTORY:SEARCH:NUMBER1:PARAMETER:
TRACE 1
:HISTory[:SEARch]:NUMBer<x>:PARamete
r:VALue?
Function Queries the specified waveform parameter’s
measured value for parameter searching.
Syntax
:HISTory[:SEARch]:NUMBer<x>:
PARameter:VALue?
<x> = 1 to 4
Example
:HISTORY:SEARCH:NUMBER1:PARAMETER:VAL
UE?
-> :HISTORY:SEARCH:NUMBER1:PARAMETER:
VALUE1.98E−03
Description When the mode is set to OFF or when the value
is otherwise immeasurable, the DLM2000 returns
“NAN” (not a number).
:HISTory[:SEARch]:NUMBer<x>:POLYgon?
Function Queries all polygonal zone search settings.
Syntax
:HISTory[:SEARch]:NUMBer<x>:POLYgon?
<x> = 1 to 4
:HISTory[:SEARch]:NUMBer<x>:POLYgon:
HPOSition
Function Sets or queries the horizontal position that will be
used for polygonal zone searching.
Syntax
:HISTory[:SEARch]:NUMBer<x>:POLYgon:H
POSition {<NRf>}
:HISTory[:SEARch]:NUMBer<x>:POLYgon:H
POSition?
<x> = 1 to 4
<NRf>=−5to5(divisions)
Example
:HISTORY:SEARCH:NUMBER1:POLYGON:HPOSI
TION 1
:HISTORY:SEARCH:NUMBER1:POLYGON:HPOSI
TION?
-> :HISTORY:SEARCH:NUMBER1:POLYGON:HP
OSITION 1.000E+00
Description When TRACe is set to XY<x>, the <NRf> is 1 to 4
(div).
:HISTory[:SEARch]:NUMBer<x>:POLYgon:
RANGe
Function Sets or queries the source window that will be
used for polygonal zone searching.
Syntax
:HISTory[:SEARch]:NUMBer<x>:POLYgon:R
ANGe {MAIN|Z1|Z2}
:HISTory[:SEARch]:NUMBer<x>:POLYgon:R
ANGe?
<x> = 1 to 4
Example
:HISTORY:SEARCH:NUMBER1:POLYGON:RAN
GE MAIN
:HISTORY:SEARCH:NUMBER1:POLYGON:RAN
GE?
-> :HISTORY:SEARCH:NUMBER1:POLYGON:RA
NGE MAIN
5.15 HISTory Group
