Code Message and Corrective Action Section
681 The data length that is necessary for the harmonics analysis function is short. —
682 The decode cannot be displayed, because the threshold level is not appropriate. —
683 Cannot execute the math function, because the display of source is OFF. Chapter 6
1
684 Logic waveforms cannot be loaded into Ref. Chapter 17
1
685 Cannot load into Ref with maximum record length. —
686 Cannot execute during roll mode.
Stop and execute again.
3.9
687 It connects with PC Application. —
688 Cannot execute on current record length. —
689 Cannot execute during Preview mode. —
691 Cannot execute after hisory search.
Reset history search and execute again.
15.2
1
692 Cannot execute, because history is not exist. —
693 Cannot execute, when the output of the print is “Multi”. 16.6
1
695 Failed to establish a DLMsync connection.
Check that the DLMsync cable is connected properly, and execute again.
19.1
1
696 DLMsync cannot be used because the firmware versions are not matched.
Update the firmware to the latest version.
—
697 DLMsync cannot be used because the /SYN option is not installed in the connected
instrument.
Connect an instrument with the /SYN option, or purchase the option and install it.
—
698 Failed to execute DLMsync auto deskew.
The proper signal may not be applied to CH1 of both instruments, or the probe may not be
connected properly.
See the help or the Features Guide for the execution conditions of auto deskew.
Chapter 22
2
1 User’s Manual, IM DLM5058-02EN
2 Features Guide, IM DLM5058-01EN
Setting Errors
Code Message and Corrective Action Section
800 Improper Date / Time setting. 3.5
801 Not allowed unless waveforms are shown. Display waveforms. Chapter 1
1
802 Source waveforms do not exist. Display source waveforms. Chapter 3
1
803 Zone waveforms do not exist. Chapter 2
1
804 Illegal expression. Chapter 6
1
806 Invalid bit assignment in the logic bus. Chapter 1
1
807 Unable to enable the trigger conditions.
Set the clock source to another group or assign bits to the group.
2.6
1
808 Cannot set this parameter with maximum record length. —
809 Cannot change the setting of the math operation, because power analysis is set. —
810 Cannot set this parameter when A-trigger is not serial bus. Chapter 2
1
811 This setting is necessary only in the case of ON display of Zoom1 and Zoom2. Chapter 10
1
812 Cannot set this parameter during interleave mode. —
813 This option is not available. —
814 The Userdefined math option is not available. —
815 The logic input option is not available. —
816 This function is not supported. —
817 The ID value cannot be set to 0. 2.17,
1
12.5
1
825 This operation cannot be executed during DLMsync. Chapter 22
2
826 This operation cannot be executed on the sub unit during DLMsync. Chapter 22
2
827 This operation cannot be executed on the sub unit during DLMsync. Execute it on the main
unit.
Chapter 22
2
828 This operation cannot be executed during DLMsync.
Stop the acquisition or wait for it to finish, and then execute.
Chapter 22
2
1 User’s Manual, IM DLM5058-02EN
2 Features Guide, IM DLM5058-01EN
