Appendix 1 Relationship between the Time Axis Setting, Sample Rate, and Record Length
When the Set Record Length Is 1.25 kpoint
(This record length can be selected on all models)
Mode
Setting
High Resolution Mode OFF High Resolution Mode ON
RealTime Interpolation Repetitive RealTime Interpolation Repetitive
Time/div
Sample
Rate
(S/s)
Display
Record
Length
(Point)
Sample
Rate
(S/s)
Display
Record
Length
(Point)
Sample
Rate
(S/s)
Display
Record
Length
(Point)
Sample
Rate
(S/s)
Display
Record
Length
(Point)
Sample
Rate
(S/s)
Display
Record
Length
(Point)
Sample
Rate
(S/s)
Display
Record
Length
(Point)
500 s 50 250 k 50 250 k 50 250 k 50 250 k 50 250 k 50 250 k
200 s 50 100 k 50 100 k 50 100 k 50 100 k 50 100 k 50 100 k
100 s 50 50 k 50 50 k 50 50 k 50 50 k 50 50 k 50 50 k
50 s 50 25 k 50 25 k 50 25 k 50 25 k 50 25 k 50 25 k
20 s 50 10 k 50 10 k 50 10 k 50 10 k 50 10 k 50 10 k
10 s 50 5 k 50 5 k 50 5 k 50 5 k 50 5 k 50 5 k
5 s 50 2.5 k 50 2.5 k 50 2.5 k 50 2.5 k 50 2.5 k 50 2.5 k
2 s 62.5 1.25 k 62.5 1.25 k 62.5 1.25 k 62.5 1.25 k 62.5 1.25 k 62.5 1.25 k
1 s 125 1.25 k 125 1.25 k 125 1.25 k 125 1.25 k 125 1.25 k 125 1.25 k
500 ms 250 1.25 k 250 1.25 k 250 1.25 k 250 1.25 k 250 1.25 k 250 1.25 k
200 ms 625 1.25 k 625 1.25 k 625 1.25 k 625 1.25 k 625 1.25 k 625 1.25 k
100 ms 1.25 k 1.25 k 1.25 k 1.25 k 1.25 k 1.25 k 1.25 k 1.25 k 1.25 k 1.25 k 1.25 k 1.25 k
50 ms 2.5 k 1.25 k 2.5 k 1.25 k 2.5 k 1.25 k 2.5 k 1.25 k 2.5 k 1.25 k 2.5 k 1.25 k
20 ms 6.25 k 1.25 k 6.25 k 1.25 k 6.25 k 1.25 k 6.25 k 1.25 k 6.25 k 1.25 k 6.25 k 1.25 k
10 ms 12.5 k 1.25 k 12.5 k 1.25 k 12.5 k 1.25 k 12.5 k 1.25 k 12.5 k 1.25 k 12.5 k 1.25 k
5 ms 25 k 1.25 k 25 k 1.25 k 25 k 1.25 k 25 k 1.25 k 25 k 1.25 k 25 k 1.25 k
2 ms 62.5 k 1.25 k 62.5 k 1.25 k 62.5 k 1.25 k 62.5 k 1.25 k 62.5 k 1.25 k 62.5 k 1.25 k
1 ms 125 k 1.25 k 125 k 1.25 k 125 k 1.25 k 125 k 1.25 k 125 k 1.25 k 125 k 1.25 k
500 µs 250 k 1.25 k 250 k 1.25 k 250 k 1.25 k 250 k 1.25 k 250 k 1.25 k 250 k 1.25 k
200 µs 625 k 1.25 k 625 k 1.25 k 625 k 1.25 k 625 k 1.25 k 625 k 1.25 k 625 k 1.25 k
100 µs 1.25 M 1.25 k 1.25 M 1.25 k 1.25 M 1.25 k 1.25 M 1.25 k 1.25 M 1.25 k 1.25 M 1.25 k
50 µs 2.5 M 1.25 k 2.5 M 1.25 k 2.5 M 1.25 k 2.5 M 1.25 k 2.5 M 1.25 k 2.5 M 1.25 k
20 µs 6.25 M 1.25 k 6.25 M 1.25 k 6.25 M 1.25 k 6.25 M 1.25 k 6.25 M 1.25 k 6.25 M 1.25 k
10 µs 12.5 M 1.25 k 12.5 M 1.25 k 12.5 M 1.25 k 12.5 M 1.25 k 12.5 M 1.25 k 12.5 M 1.25 k
5 µs 25 M 1.25 k 25 M 1.25 k 25 M 1.25 k 25 M 1.25 k 25 M 1.25 k 25 M 1.25 k
2 µs 62.5 M 1.25 k 62.5 M 1.25 k 62.5 M 1.25 k 62.5 M 1.25 k 62.5 M 1.25 k 62.5 M 1.25 k
1 µs 125 M 1.25 k 125 M 1.25 k 125 M 1.25 k 125 M 1.25 k 125 M 1.25 k 125 M 1.25 k
500 ns 250 M 1.25 k 250 M 1.25 k 250 M 1.25 k 250 M 1.25 k 250 M 1.25 k 250 M 1.25 k
200 ns 625 M 1.25 k 625 M 1.25 k 625 M 1.25 k 625 M 1.25 k 625 M 1.25 k 625 M 1.25 k
100 ns 1.25 G 1.25 k 1.25 G 1.25 k 1.25 G 1.25 k 1.25 G 1.25 k 1.25 G 1.25 k 1.25 G 1.25 k
50 ns 2.5 G 1.25 k 2.5 G 1.25 k 2.5 G 1.25 k 1.25 G 625 2.5 G 1.25 k 2.5 G 1.25 k
20 ns 2.5 G 500 5 G 1 k 5 G 1 k 1.25 G 250 5 G 1 k 5 G 1 k
10 ns 2.5 G 250 12.5 G 1.25 k 12.5 G 1.25 k 1.25 G 125 12.5 G 1.25 k 12.5 G 1.25 k
5 ns 2.5 G 125 25 G 1.25 k 25 G 1.25 k 1.25 G 62.5 25 G 1.25 k 25 G 1.25 k
2 ns 2.5 G 50 62.5 G 1.25 k 62.5 G 1.25 k 1.25 G 25 62.5 G 1.25 k 62.5 G 1.25 k
1 ns 2.5 G 25 125 G 1.25 k 125 G 1.25 k 1.25 G 12.5 125 G 1.25 k 125 G 1.25 k
Values outside of the thick borders have been calculated in real-time sampling mode.
: Roll mode
