Appendix 1 Relationship between the Time Axis Setting, Sample Rate, and Record Length
When the Set Record Length Is 12.5 kpoint
(This record length can be selected on all models)
Mode
Setting
High Resolution Mode OFF High Resolution Mode ON
RealTime Interpolation Repetitive RealTime Interpolation Repetitive
Time/div
Sample
Rate
(S/s)
Display
Record
Length
(Point)
Sample
Rate
(S/s)
Display
Record
Length
(Point)
Sample
Rate
(S/s)
Display
Record
Length
(Point)
Sample
Rate
(S/s)
Display
Record
Length
(Point)
Sample
Rate
(S/s)
Display
Record
Length
(Point)
Sample
Rate
(S/s)
Display
Record
Length
(Point)
500 s 50 250 k 50 250 k 50 250 k 50 250 k 50 250 k 50 250 k
200 s 50 100 k 50 100 k 50 100 k 50 100 k 50 100 k 50 100 k
100 s 50 50 k 50 50 k 50 50 k 50 50 k 50 50 k 50 50 k
50 s 50 25 k 50 25 k 50 25 k 50 25 k 50 25 k 50 25 k
20 s 62.5 12.5 k 62.5 12.5 k 62.5 12.5 k 62.5 12.5 k 62.5 12.5 k 62.5 12.5 k
10 s 125 12.5 k 125 12.5 k 125 12.5 k 125 12.5 k 125 12.5 k 125 12.5 k
5 s 250 12.5 k 250 12.5 k 250 12.5 k 250 12.5 k 250 12.5 k 250 12.5 k
2 s 625 12.5 k 625 12.5 k 625 12.5 k 625 12.5 k 625 12.5 k 625 12.5 k
1 s 1.25 k 12.5 k 1.25 k 12.5 k 1.25 k 12.5 k 1.25 k 12.5 k 1.25 k 12.5 k 1.25 k 12.5 k
500 ms 2.5 k 12.5 k 2.5 k 12.5 k 2.5 k 12.5 k 2.5 k 12.5 k 2.5 k 12.5 k 2.5 k 12.5 k
200 ms 6.25 k 12.5 k 6.25 k 12.5 k 6.25 k 12.5 k 6.25 k 12.5 k 6.25 k 12.5 k 6.25 k 12.5 k
100 ms 12.5 k 12.5 k 12.5 k 12.5 k 12.5 k 12.5 k 12.5 k 12.5 k 12.5 k 12.5 k 12.5 k 12.5 k
50 ms 25 k 12.5 k 25 k 12.5 k 25 k 12.5 k 25 k 12.5 k 25 k 12.5 k 25 k 12.5 k
20 ms 62.5 k 12.5 k 62.5 k 12.5 k 62.5 k 12.5 k 62.5 k 12.5 k 62.5 k 12.5 k 62.5 k 12.5 k
10 ms 125 k 12.5 k 125 k 12.5 k 125 k 12.5 k 125 k 12.5 k 125 k 12.5 k 125 k 12.5 k
5 ms 250 k 12.5 k 250 k 12.5 k 250 k 12.5 k 250 k 12.5 k 250 k 12.5 k 250 k 12.5 k
2 ms 625 k 12.5 k 625 k 12.5 k 625 k 12.5 k 625 k 12.5 k 625 k 12.5 k 625 k 12.5 k
1 ms 1.25 M 12.5 k 1.25 M 12.5 k 1.25 M 12.5 k 1.25 M 12.5 k 1.25 M 12.5 k 1.25 M 12.5 k
500 µs 2.5 M 12.5 k 2.5 M 12.5 k 2.5 M 12.5 k 2.5 M 12.5 k 2.5 M 12.5 k 2.5 M 12.5 k
200 µs 6.25 M 12.5 k 6.25 M 12.5 k 6.25 M 12.5 k 6.25 M 12.5 k 6.25 M 12.5 k 6.25 M 12.5 k
100 µs 12.5 M 12.5 k 12.5 M 12.5 k 12.5 M 12.5 k 12.5 M 12.5 k 12.5 M 12.5 k 12.5 M 12.5 k
50 µs 25 M 12.5 k 25 M 12.5 k 25 M 12.5 k 25 M 12.5 k 25 M 12.5 k 25 M 12.5 k
20 µs 62.5 M 12.5 k 62.5 M 12.5 k 62.5 M 12.5 k 62.5 M 12.5 k 62.5 M 12.5 k 62.5 M 12.5 k
10 µs 125 M 12.5 k 125 M 12.5 k 125 M 12.5 k 125 M 12.5 k 125 M 12.5 k 125 M 12.5 k
5 µs 250 M 12.5 k 250 M 12.5 k 250 M 12.5 k 250 M 12.5 k 250 M 12.5 k 250 M 12.5 k
2 µs 625 M 12.5 k 625 M 12.5 k 625 M 12.5 k 625 M 12.5 k 625 M 12.5 k 625 M 12.5 k
1 µs 1.25 G 12.5 k 1.25 G 12.5 k 1.25 G 12.5 k 1.25 G 12.5 k 1.25 G 12.5 k 1.25 G 12.5 k
500 ns 2.5 G 12.5 k 2.5 G 12.5 k 2.5 G 12.5 k 1.25 G 6.25 k 2.5 G 12.5 k 2.5 G 12.5 k
200 ns 2.5 G 5 k 5 G 10 k 5 G 10 k 1.25 G 2.5 k 5 G 10 k 5 G 10 k
100 ns 2.5 G 2.5 k 12.5 G 12.5 k 12.5 G 12.5 k 1.25 G 1.25 k 12.5 G 12.5 k 12.5 G 12.5 k
50 ns 2.5 G 1.25 k 25 G 12.5 k 25 G 12.5 k 1.25 G 625 25 G 12.5 k 25 G 12.5 k
20 ns 2.5 G 500 62.5 G 12.5 k 62.5 G 12.5 k 1.25 G 250 62.5 G 12.5 k 62.5 G 12.5 k
10 ns 2.5 G 250 125 G 12.5 k 125 G 12.5 k 1.25 G 125 125 G 12.5 k 125 G 12.5 k
5 ns 2.5 G 125 250 G 12.5 k 250 G 12.5 k 1.25 G 62.5 250 G 12.5 k 250 G 12.5 k
2 ns 2.5 G 50 250 G 5 k 250 G 5 k 1.25 G 25 250 G 5 k 250 G 5 k
1 ns 2.5 G 25 250 G 2.5 k 250 G 2.5 k 1.25 G 12.5 250 G 2.5 k 250 G 2.5 k
Values outside of the thick borders have been calculated in real-time sampling mode.
