YOKOGAWA DLM5034 User Manual

App-4
IM DLM5058-03EN
When the Set Record Length Is 125 kpoint
(This record length can be selected on all models)
Mode
Setting
High Resolution Mode OFF High Resolution Mode ON
RealTime Interpolation Repetitive RealTime Interpolation Repetitive
Time/div
Sample
Rate
(S/s)
Display
Record
Length
(Point)
Sample
Rate
(S/s)
Display
Record
Length
(Point)
Sample
Rate
(S/s)
Display
Record
Length
(Point)
Sample
Rate
(S/s)
Display
Record
Length
(Point)
Sample
Rate
(S/s)
Display
Record
Length
(Point)
Sample
Rate
(S/s)
Display
Record
Length
(Point)
500 s 50 250 k 50 250 k 50 250 k 50 250 k 50 250 k 50 250 k
200 s 62.5 125 k 62.5 125 k 62.5 125 k 62.5 125 k 62.5 125 k 62.5 125 k
100 s 125 125 k 125 125 k 125 125 k 125 125 k 125 125 k 125 125 k
50 s 250 125 k 250 125 k 250 125 k 250 125 k 250 125 k 250 125 k
20 s 625 125 k 625 125 k 625 125 k 625 125 k 625 125 k 625 125 k
10 s 1.25 k 125 k 1.25 k 125 k 1.25 k 125 k 1.25 k 125 k 1.25 k 125 k 1.25 k 125 k
5 s 2.5 k 125 k 2.5 k 125 k 2.5 k 125 k 2.5 k 125 k 2.5 k 125 k 2.5 k 125 k
2 s 6.25 k 125 k 6.25 k 125 k 6.25 k 125 k 6.25 k 125 k 6.25 k 125 k 6.25 k 125 k
1 s 12.5 k 125 k 12.5 k 125 k 12.5 k 125 k 12.5 k 125 k 12.5 k 125 k 12.5 k 125 k
500 ms 25 k 125 k 25 k 125 k 25 k 125 k 25 k 125 k 25 k 125 k 25 k 125 k
200 ms 62.5 k 125 k 62.5 k 125 k 62.5 k 125 k 62.5 k 125 k 62.5 k 125 k 62.5 k 125 k
100 ms 125 k 125 k 125 k 125 k 125 k 125 k 125 k 125 k 125 k 125 k 125 k 125 k
50 ms 250 k 125 k 250 k 125 k 250 k 125 k 250 k 125 k 250 k 125 k 250 k 125 k
20 ms 625 k 125 k 625 k 125 k 625 k 125 k 625 k 125 k 625 k 125 k 625 k 125 k
10 ms 1.25 M 125 k 1.25 M 125 k 1.25 M 125 k 1.25 M 125 k 1.25 M 125 k 1.25 M 125 k
5 ms 2.5 M 125 k 2.5 M 125 k 2.5 M 125 k 2.5 M 125 k 2.5 M 125 k 2.5 M 125 k
2 ms 6.25 M 125 k 6.25 M 125 k 6.25 M 125 k 6.25 M 125 k 6.25 M 125 k 6.25 M 125 k
1 ms 12.5 M 125 k 12.5 M 125 k 12.5 M 125 k 12.5 M 125 k 12.5 M 125 k 12.5 M 125 k
500 µs 25 M 125 k 25 M 125 k 25 M 125 k 25 M 125 k 25 M 125 k 25 M 125 k
200 µs 62.5 M 125 k 62.5 M 125 k 62.5 M 125 k 62.5 M 125 k 62.5 M 125 k 62.5 M 125 k
100 µs 125 M 125 k 125 M 125 k 125 M 125 k 125 M 125 k 125 M 125 k 125 M 125 k
50 µs 250 M 125 k 250 M 125 k 250 M 125 k 250 M 125 k 250 M 125 k 250 M 125 k
20 µs 625 M 125 k 625 M 125 k 625 M 125 k 625 M 125 k 625 M 125 k 625 M 125 k
10 µs 1.25 G 125 k 1.25 G 125 k 1.25 G 125 k 1.25 G 125 k 1.25 G 125 k 1.25 G 125 k
5 µs 2.5 G 125 k 2.5 G 125 k 2.5 G 125 k 1.25 G 62.5 k 2.5 G 125 k 2.5 G 125 k
2 µs 2.5 G 50 k 5 G 100 k 5 G 100 k 1.25 G 25 k 5 G 100 k 5 G 100 k
1 µs 2.5 G 25 k 12.5 G 125 k 12.5 G 125 k 1.25 G 12.5 k 12.5 G 125 k 12.5 G 125 k
500 ns 2.5 G 12.5 k 25 G 125 k 25 G 125 k 1.25 G 6.25 k 25 G 125 k 25 G 125 k
200 ns 2.5 G 5 k 62.5 G 125 k 62.5 G 125 k 1.25 G 2.5 k 62.5 G 125 k 62.5 G 125 k
100 ns 2.5 G 2.5 k 125 G 125 k 125 G 125 k 1.25 G 1.25 k 125 G 125 k 125 G 125 k
50 ns 2.5 G 1.25 k 250 G 125 k 250 G 125 k 1.25 G 625 250 G 125 k 250 G 125 k
20 ns 2.5 G 500 250 G 50 k 250 G 50 k 1.25 G 250 250 G 50 k 250 G 50 k
10 ns 2.5 G 250 250 G 25 k 250 G 25 k 1.25 G 125 250 G 25 k 250 G 25 k
5 ns 2.5 G 125 250 G 12.5 k 250 G 12.5 k 1.25 G 62.5 250 G 12.5 k 250 G 12.5 k
2 ns 2.5 G 50 250 G 5 k 250 G 5 k 1.25 G 25 250 G 5 k 250 G 5 k
1 ns 2.5 G 25 250 G 2.5 k 250 G 2.5 k 1.25 G 12.5 250 G 2.5 k 250 G 2.5 k
Values outside of the thick borders have been calculated in real-time sampling mode.
: Roll mode
Appendix 1 Relationship between the Time Axis Setting, Sample Rate, and Record Length
