When the Set Record Length Is 50 Mpoint
(This record length can be selected on all models)
Mode
Setting
High Resolution Mode OFF High Resolution Mode ON
RealTime Interpolation
*
Repetitive RealTime Interpolation
*
Repetitive
Time/div
Sample
Rate
(S/s)
Display
Record
Length
(Point)
Sample
Rate
(S/s)
Display
Record
Length
(Point)
Sample
Rate
(S/s)
Display
Record
Length
(Point)
Sample
Rate
(S/s)
Display
Record
Length
(Point)
Sample
Rate
(S/s)
Display
Record
Length
(Point)
Sample
Rate
(S/s)
Display
Record
Length
(Point)
500 s 10 k 50 M 10 k 50 M
Repetitive
sampling mode
cannot be used
with this record
length.
10 k 50 M 10 k 50 M
Repetitive
sampling mode
cannot be used
with this record
length.
200 s 25 k 50 M 25 k 50 M 25 k 50 M 25 k 50 M
100 s 50 k 50 M 50 k 50 M 50 k 50 M 50 k 50 M
50 s 100 k 50 M 100 k 50 M 100 k 50 M 100 k 50 M
20 s 250 k 50 M 250 k 50 M 250 k 50 M 250 k 50 M
10 s 500 k 50 M 500 k 50 M 500 k 50 M 500 k 50 M
5 s 1 M 50 M 1 M 50 M 1 M 50 M 1 M 50 M
2 s 2.5 M 50 M 2.5 M 50 M 2.5 M 50 M 2.5 M 50 M
1 s 5 M 50 M 5 M 50 M 5 M 50 M 5 M 50 M
500 ms 10 M 50 M 10 M 50 M 10 M 50 M 10 M 50 M
200 ms 25 M 50 M 25 M 50 M 25 M 50 M 25 M 50 M
100 ms 50 M 50 M 50 M 50 M 50 M 50 M 50 M 50 M
50 ms 100 M 50 M 100 M 50 M 100 M 50 M 100 M 50 M
20 ms 250 M 50 M 250 M 50 M 250 M 50 M 250 M 50 M
10 ms 500 M 50 M 500 M 50 M 500 M 50 M 500 M 50 M
5 ms 625 M 31.25 M 625 M 31.25 M 625 M 31.25 M 625 M 31.25 M
2 ms 2.5 G 50 M 2.5 G 50 M 1.25 G 25 M 2.5 G 50 M
1 ms 2.5 G 25 M 5 G 50 M 1.25 G 12.5 M 5 G 50 M
500 µs 2.5 G 12.5 M 10 G 50 M 1.25 G 6.25 M 10 G 50 M
200 µs 2.5 G 5 M 25 G 50 M 1.25 G 2.5 M 25 G 50 M
100 µs 2.5 G 2.5 M 50 G 50 M 1.25 G 1.25 M 50 G 50 M
50 µs 2.5 G 1.25 M 100 G 50 M 1.25 G 625 k 100 G 50 M
20 µs 2.5 G 500 k 250 G 50 M 1.25 G 250 k 250 G 50 M
10 µs 2.5 G 250 k 250 G 25 M 1.25 G 125 k 250 G 25 M
5 µs 2.5 G 125 k 250 G 12.5 M 1.25 G 62.5 k 250 G 12.5 M
2 µs 2.5 G 50 k 250 G 5 M 1.25 G 25 k 250 G 5 M
1 µs 2.5 G 25 k 250 G 2.5 M 1.25 G 12.5 k 250 G 2.5 M
500 ns 2.5 G 12.5 k 250 G 1.25 M 1.25 G 6.25 k 250 G 1.25 M
200 ns 2.5 G 5 k 250 G 500 k 1.25 G 2.5 k 250 G 500 k
100 ns 2.5 G 2.5 k 250 G 250 k 1.25 G 1.25 k 250 G 250 k
50 ns 2.5 G 1.25 k 250 G 125 k 1.25 G 625 250 G 125 k
20 ns 2.5 G 500 250 G 50 k 1.25 G 250 250 G 50 k
10 ns 2.5 G 250 250 G 25 k 1.25 G 125 250 G 25 k
5 ns 2.5 G 125 250 G 12.5 k 1.25 G 62.5 250 G 12.5 k
2 ns 2.5 G 50 250 G 5 k 1.25 G 25 250 G 5 k
1 ns 2.5 G 25 250 G 2.5 k 1.25 G 12.5 250 G 2.5 k
Values outside of the thick borders have been calculated in real-time sampling mode.
If there is no memory option or with the /M1S option or /M1 option, acquisition with this record length is performed in single mode.
* If there is no memory option, with this record length, interpolation mode cannot be used.
: Roll mode
Appendix 1 Relationship between the Time Axis Setting, Sample Rate, and Record Length
