IM 253401-01E
14-12
14.4 Error Codes and Corrective Actions
Lower the baud rate.
54
55
56
57
58
59
390
Power factor exceeded "2" during
measurement of power factor.
"PFErr" was displayed at the end of power
factor computation during measurement of
phase angle.
Input level was too low or below
measurement range during measurement of
frequency. "Err-Lo" is displayed.
Measured frequency exceeded the
measurement range. "Err-Hi" is displayed.
Computation overflow occurred.
"oF" is displayed.
Harmonic analysis becomes "FrqEr".
Overrun error.
6-1
6-1, 6-2
5-3
5-3
2-4
8-2
12-6
Error Codes regarding Self Diagnosis
Error Code Description Corrective Action
60 Data failure of set-up parameters backup. -
(set-up parameters are set to default)
61 EEPROM (element 1) failure. Service is required.
62 EEPROM (element 2) failure. Service is required
63 EEPROM (element 3) failure. Service is required.
64 EEPROM (D/A board) failure. Service is required.
65 A/D converter (element 1) failure. Service is required.
66 A/D converter (element 2) failure. Service is required.
67 A/D converter (element 3) failure. Service is required.
68 Data file failure File will be initialized
(measurement data, set-up parameter file failure) automatically.
69 Lithium battery voltage drop. Service is required.
71 DSP communications failure. Service is required.
75 DSP1 program RAM failure. Service is required.
76 DSP2 program RAM failure. Service is required.
77 DSP3 program RAM failure. Service is required.
79 ROM checksum error. Service is required.
80 RAM read/write check error. Service is required.
81 DSP1 data RAM error. Service is required.
82 DSP2 data RAM error. Service is required.
83 DSP3 data RAM error. Service is required.
84 DSP1 sample clock failure. Service is required.
85 DSP2 sample clock failure. Service is required.
86 DSP3 sample clock failure. Service is required.
90 Incorrect board combination. Service is required.
91 Incorrect board combination. Service is required.
To Next Page
