IM 253401-01E
3-13
3
Before Operation
3.8 Turning the Power ON/OFF
Item to be Checked before Turning ON the Power
• Check that the instrument is installed correctly (refer to section 3.2, page 3-2).
• Check that the power cord is connected properly (refer to section 3.7, page 3-12).
Location of the Power Switch
The power switch is located in the lower left corner of the front panel.
Turning the Power ON
Turning the power ON will result in staring the test program, which checks each memory.
When the results of these checks are all satisfactory, opening, messages will appear as described
on the next page, after which the instrument will be ready for measurement.
When the test program results in displaying error codes, proper operation of the instrument
cannot be performed. Immediately turn OFF the power and contact you nearest representative.
Addresses may be found on the back cover of this manual. When contacting your
representative, inform him of the name, suffix and No. code as on the right side panel, and of
the displayed error code(s).
Note
• In case of an error code, refer to section 14.4, page 14-11, for a description and corrective action.
•A warm-up time of approx.30 minutes is required before all spesifications of the instrument can be met.
Turning the Power OFF
When turning the power OFF, the previous set-up parameters will be kept. Consequently,
turning the power ON again will result in the appearance of the setting condition of the previous
measurements.
Note
The instrument uses a lithium battery to back up set-up information. The life of the battery under normal
operating temperature of 23˚C is approx. ten years. When the battery life is exhausted, turning ON the
power switch will result in an error code and the battery needs to be replaced. Never replace the battery
yourself, but inform your nearest representative. Addresses may be found on the back cover of this
manual.
To Next Page
