IM 253401-01E
App2-8
Appendix 2.3 Commands
Appendix 2.3 Commands
2.3.1Command List
Command Description Page
AOUTput Group
:AOUTput?
Queries all settings related to D/A output. App. 2-11
:AOUTput:CHANnel<x>
Sets/queries the D/A output item. App. 2-11
:AOUTput:IRTime
Sets/queries the preset integration time for D/A output of integrated values. App. 2-11
:AOUTput:PRESet
Sets the default value as D/A output items. App. 2-11
COMMunicateG roup
:COMMunicate?
Queries all settings related to communication. App. 2-12
:COMMunicate:HEADer
Sets/queries whether a header is to be added. App. 2-12
:COMMunicate:LOCKout
Sets/cancels local lockout. App. 2-12
:COMMunicate:REMote
Sets remote/local condition. App. 2-12
:COMMunicate:STATus?
Queries the status of a specified circuit. App. 2-13
:COMMunicate:VERBose
Sets/queries the response to be in full or abbreviated form. App. 2-13
:COMMunicate:WAIT
Waits until one of the specified extended event occurs. App. 2-13
:COMMunicate:WAIT?
Generates a response when on of the specified extended events occurs. App. 2-13
CONFigure Group
:CONFigure?
Queries all settings related to the measurement conditions. App. 2-15
[:CONFigure]:AVERaging?
Queries all settings related to the averaging function. App. 2-15
[:CONFigure]:AVERaging[:STATe]
Sets/queries averaging ON/OFF. App. 2-15
[:CONFigure]:AVERaging:TYPE
Sets/queries averaging type and constant. App. 2-15
[:CONFigure]:CURRent?
Queries all settings related to the current range. App. 2-15
[:CONFigure]:CURRent:AUTO
Sets/queries the current auto range ON/OFF. App. 2-15
[:CONFigure]:CURRent:ESCaling?
Queries all settings related to the external sensor. App. 2-15
[:CONFigure]:CURRent:ESCaling[:ALL]
Sets the scaling values for the external sensor for all elements at once. App. 2-15
[:CONFigure]:CURRent:ESCaling:ELEMent<x>
Sets/queries the scaling values for the external sensor for each element. App. 2-15
[:CONFigure]:CURRent:RANGe
Sets/queries the current range. App. 2-15
[:CONFigure]:FILTer
Sets/queries the filter ON/OFF. App. 2-15
[:CONFigure]:MODE
Sets/queries the measurement mode. App. 2-15
[:CONFigure]:SCALing?
Queries all settings related to the scaling function. App. 2-16
[:CONFigure]:SCALing:{PT|CT|SFACtor}?
Queries all settings related to scaling value for {voltage|current|power}. App. 2-16
[:CONFigure]:SCALing:{PT|CT|SFACtor}[:ALL]
Sets the scaling values for all elements of {voltage|current|power}. App. 2-16
[:CONFigure]:SCALing:{PT|CT|SFACtor}:ELEMent<x>
Sets the scaling values for each element of {voltage|current|power}. App. 2-16
[:CONFigure]:SCALing[:STATe]
Sets/queries the scaling function ON/OFF. App. 2-16
[:CONFigure]:VOLTage?
Queries all settings related to the voltage range. App. 2-16
[:CONFigure]:VOLTage:AUTO
Sets/queries the voltage auto range ON/OFF. App. 2-16
[:CONFigure]:VOLTage:RANGe
Sets/queries the voltage range. App. 2-16
[:CONFigure]:WIRing
Sets/queries the wiring method. App. 2-16
DISPlay Group
:DISPlay<x>?
Queries all the display settings. App. 2-17
:DISPlay<x>:ELEMent
Sets/queries the element to be displayed. App. 2-17
:DISPlay<x>:FUNCtion
Sets/queries the function to be displayed. App. 2-17
:DISPlay<x>:MODE
Sets/queries the contents of the display. App. 2-17
HARMonics Group
:HARMonics?
Queries all settings related to harmonic analysis. App. 2-18
:HARMonics:DISPlay?
Queries all settings related to the display in case of harmonic analysis. App. 2-18
:HARMonics:DISPlay:ORDer
Sets/queries the order of the harmonic component to be shown on display B. App. 2-18
:HARMonics:ELEMent
Sets/queries the element for harmonic analysis. App. 2-18
:HARMonics[:STATe]
Sets/queries the harmonic analysis mode ON/OFF. App. 2-18
:HARMonics:SYNChronize
Sets/queries the input to be used as PLL source. App. 2-18
:HARMonics:THD
Sets/queries the computation method for harmonic distortion. App. 2-18
