IM 253401-01E
9-3
9
Storing / Recalling
9.1 Storing/Recalling Measured Data
Recalling Measured Data (Retrieving Data from the Internal Memory)
After displaying data stored in the internal memory on the panel, you can use all display
functions and carry out integration and display these data. Furthermore, by using the
communication function, data can be output.
Items which can be recalled
all data which can be stored.
Aborting Recalling
- when all stored data are retrieved;
- when during the recall process “oFF” is selected at the store ON/OFF setting.
Setting the Recalling Interval
Sets the time during which recalling will be carried out.
• Setting range : 00.00.00 (0hrs, 0min, 0sec) to 99.59.59 (99hrs, 59min, 59sec)
• Initial value : 00.00.00
When recalling normal measured data, the interval will become 250ms when the setting is
00.00.00.
When recalling harmonic analysis data, the interval will become 1s when the setting is 00.00.00.
Recalling ON/OFF
After having set the recalling interval, select the recall menu once again. The initial value is
oFF.
•on: Recalling will start by pressing the ENTER key after selecting “on”; the RECALL
indicator will light while recalling is in progress.
• oFF : Recalling will stop by pressing the ENTER key after selecting “oFF”; the RECALL
indicator will extinguish
Note
• During recalling, the measurement conditions/range
*1
will become as those of the data being recalled.
After recalling finishes, the original measurement conditions will return.
*1 measurement range, measurement mode, filter ON/OFF, scaling ON/OFF, scaling values, averaging
ON/OFF, averaging mode, averaging values, integration mode, integration time, harmonic analysis
function ON/OFF, PLL source, input element, computation method of harmonic distortion factor
• When recalling data to a personal computer by communication interface, data might be cut due to the
data length or used personal computer. In such a case, increase the recalling interval.
