YOKOGAWA WT310EH User Manual

App-14
IM WT310E-01EN
Appendix 3 Power Range
• Thetablebelowshowsactualvoltageandcurrentrangecombinationsandthepowerrangesthat
result from them. The table shows the active power range (unit: W). The same ranges are set for
apparentpower(unit:VA)andreactivepower(unit:var).JustreadtheunitasVAorvar.
• Thetableisforwhenthenumberofdisplayeddigitsisfive.Ifthenumberofdisplayeddigitsis4,
the least significant digit is removed from the values in the table. For information on how to set the
number of displayed digits, see section 4.7.
WT310E
When the Crest Factor Is Set to 3
Voltage Range Current Range
(V) 500.00 mA 1.0000 A 2.0000 A 5.0000 A 10.000 A 20.000 A
15.000 7.5000W 15.000W 30.000 W 75.000W 150.00W 300.00 W
30.000 15.000W 30.000 W 60.000 W 150.00W 300.00 W 600.00 W
60.000 30.000 W 60.000 W 120.00 W 300.00 W 600.00 W 1.2000 kW
150.00 75.000W 150.00W 300.00 W 750.00W 1.5000kW 3.0000 kW
300.00 150.00W 300.00 W 600.00 W 1.5000kW 3.0000 kW 6.0000 kW
600.00 300.00 W 600.00 W 1.2000 kW 3.0000 kW 6.0000 kW 12.000 kW
Voltage Range Current Range
(V) 5.0000 mA 10.000 mA 20.000 mA 50.000 mA 100.00 mA 200.00 mA
15.000 75.000mW 150.00mW 300.00 mW 750.00mW 1.5000W 3.0000 W
30.000 150.00mW 300.00 mW 600.00 mW 1.5000W 3.0000 W 6.0000 W
60.000 300.00 mW 600.00 mW 1.2000 W 3.0000 W 6.0000 W 12.000 W
150.00 750.00mW 1.5000W 3.0000 W 7.5000W 15.000W 30.000 W
300.00 1.5000W 3.0000 W 6.0000 W 15.000W 30.000 W 60.000 W
600.00 3.0000 W 6.0000 W 12.000 W 30.000 W 60.000 W 120.00 W
When the Crest Factor Is Set to 6 or 6A
Voltage Range Current Range
(V) 250.00 mA 500.00 mA 1.0000 A 2.5000 A 5.0000 A 10.000 A
7.5000 1.8750W 3.7500W 7.5000W 18.750W 37.500W 75.000W
15.000 3.7500W 7.5000W 15.000W 37.500W 75.000W 150.00W
30.000 7.5000W 15.000W 30.000 W 75.000W 150.00W 300.00 W
75.000 18.750W 37.500W 75.000W 187.50W 375.00W 750.00W
150.00 37.500W 75.000W 150.00W 375.00W 750.00W 1.5000kW
300.00 75.000W 150.00W 300.00 W 750.00W 1.5000kW 3.0000 kW
Voltage Range Current Range
(V) 2.5000 mA 5.0000 mA 10.000 mA 25.000 mA 50.000 mA 100.00 mA
7.5000 18.750mW 37.500mW 75.000mW 187.50mW 375.00mW 750.00mW
15.000 37.500mW 75.000mW 150.00mW 375.00mW 750.00mW 1.5000W
30.000 75.000mW 150.00mW 300.00 mW 750.00mW 1.5000W 3.0000 W
75.000 187.50mW 375.00mW 750.00mW 1.8750W 3.7500W 7.5000W
150.00 375.00mW 750.00mW 1.5000W 3.7500W 7.5000W 15.000W
300.00 750.00mW 1.5000W 3.0000 W 7.5000W 15.000W 30.000 W
