App-16
IM WT310E-01EN
WT332E/WT333E
When the Crest Factor Is Set to 3
Wiring System Voltage Range Current Range
(V) 500.00 mA 1.0000 A 2.0000 A 5.0000 A 10.000 A 20.000 A
Single-phase, two-wire 15.000 7.5000W 15.000W 30.000 W 75.000W 150.00W 300.00 W
(1P2W) 30.000 15.000W 30.000 W 60.000 W 150.00W 300.00 W 600.00 W
60.000 30.000 W 60.000 W 120.00 W 300.00 W 600.00 W 1.2000 kW
150.00 75.000W 150.00W 300.00 W 750.00W 1.5000kW 3.0000 kW
300.00 150.00W 300.00 W 600.00 W 1.5000kW 3.0000 kW 6.0000 kW
600.00 300.00 W 600.00 W 1.2000 kW 3.0000 kW 6.0000 kW 12.000 kW
Single-phase, three-wire 15.000 15.000W 30.000 W 60.000 W 150.00W 300.00 W 600.00 W
(1P3W), 30.000 30.000 W 60.000 W 120.00 W 300.00 W 600.00 W 1.2000 kW
Three-phase, three-wire 60.000 60.000 W 120.00 W 240.00 W 600.00 W 1.2000 kW 2.4000 kW
(3P3W), 150.00 150.00W 300.00 W 600.00 W 1.5000kW 3.0000 kW 6.0000 kW
Three-voltage, three-
current measurement
method
300.00 300.00 W 600.00 W 1.2000 kW 3.0000 kW 6.0000 kW 12.000 kW
(3V3A) 600.00 600.00 W 1.2000 kW 2.4000 kW 6.0000 kW 12.000 kW 24.000 kW
Three-phase, four-wire 15.000 22.500W 45.000W 90.000 W 225.00W 450.00W 900.00 W
(3P4W) 30.000 45.000W 90.000 W 180.00W 450.00W 900.00 W 1.8000kW
60.000 90.000 W 180.00W 360.00 W 900.00 W 1.8000kW 3.6000 kW
150.00 225.00W 450.00W 900.00 W 2.2500kW 4.5000kW 9.0000 kW
300.00 450.00W 900.00 W 1.8000kW 4.5000kW 9.0000 kW 18.000kW
600.00 900.00 W 1.8000kW 3.6000 kW 9.0000 kW 18.000kW 36.000 kW
When the Crest Factor Is Set to 6 or 6A
Wiring System Voltage Range Current Range
(V) 250.00 mA 500.00 mA 1.0000 A 2.5000 A 5.0000 A 10.000 A
Single-phase, two-wire 7.5000 1.8750W 3.7500W 7.5000W 18.750W 37.500W 75.000W
(1P2W) 15.000 3.7500W 7.5000W 15.000W 37.500W 75.000W 150.00W
30.000 7.5000W 15.000W 30.000 W 75.000W 150.00W 300.00 W
75.000 18.750W 37.500W 75.000W 187.50W 375.00W 750.00W
150.00 37.500W 75.000W 150.00W 375.00W 750.00W 1.5000kW
300.00 75.000W 150.00W 300.00 W 750.00W 1.5000kW 3.0000 kW
Single-phase, three-
wire
7.5000 3.7500W 7.5000W 15.000W 37.500W 75.000W 150.00W
(1P3W), 15.000 7.5000W 15.000W 30.000 W 75.000W 150.00W 300.00 W
Three-phase, three-wire 30.000 15.000W 30.000 W 60.000 W 150.00W 300.00 W 600.00 W
(3P3W), 75.000 37.500W 75.000W 150.00W 375.00W 750.00W 1.5000kW
Three-voltage, three-
current measurement
method
150.00 75.000W 150.00W 300.00 W 750.00W 1.5000kW 3.0000 kW
(3V3A) 300.00 150.00W 300.00 W 600.00 W 1.5000kW 3.0000 kW 6.0000 kW
Three-phase, four-wire 7.5000 5.6250W 11.250W 22.500W 56.250W 112.50W 225.00W
(3P4W) 15.000 11.250W 22.500W 45.000W 112.50W 225.00W 450.00W
30.000 22.500W 45.000W 90.000 W 225.00W 450.00W 900.00 W
75.000 56.250W 112.50W 225.00W 562.50W 1.1250kW 2.2500kW
150.00 112.50W 225.00W 450.00W 1.1250kW 2.2500kW 4.5000kW
300.00 225.00W 450.00W 900.00 W 2.2500kW 4.5000kW 9.0000 kW
Appendix 3 Power Range
