YOKOGAWA WT310EH User Manual

2-13
IM WT310E-01EN
Measurement Conditions
1
2
3
4
5
6
7
8
App
Index
2.5 Setting the Scaling Feature When Using a VT
or CT
Procedure
Follow the procedure indicated by the thick lines in the following menu.
Scaling Coefficients
Select the scaling feature.
(Display B)
1.
2.
3.
(Display C)
5.
4.
On the WT310E/WT310EH
On the WT332E/WT333E
6.,14.
7.
9.
Select an input element.
(Display C)
Set the VT ratio.
(Display B)
Set the CT ratio.
(Display C)
11.
10. The same as step 8.
Set the power
coefficient.
(Display D)
13.
12.
The same as
step 8.
15.
Confirm the setting. Close menu.
8.
Press and to set the number.
Press to move the decimal point.
Press to move the digit.
7.
Set the VT ratio.
(Display B)
Set the CT ratio.
(Display C)
9.
8. The same as step 6.
Set the power coefficient.
(Display D)
10. The same as step 6.
6.
Press and to set the number.
Press to move the decimal point.
Press to move the digit.
11.
Confirm the setting.
Close menu.
12.
16.
Note
The input element selection menu (ALL/EL1/EL2/EL3/End) will not appear on the WT310E or WT310EH.
