2-20

IM WT310E-01EN

Frequency Filter

Thisfilterisonlyappliedtothefrequencymeasurementcircuit.Thecutofffrequencyis500Hz.

Becausethisinstrumentmakesmeasurementsinsyncwiththeinputsignal,thefrequencyoftheinput

signal must be measured correctly. The default setting is oFF.

• on:ThefrequencyfilterisenabledandtheFREQindicatorilluminates.

• oFF:Thefrequencyfilterisdisabled.TheFREQindicatorturnsoff.

Even if you enable the frequency filter, the measured voltage and current values will include harmonic

components.

Note

You cannot enable or disable input filters between the time when integration is started and the time when it is

stopped and reset.

2.9 Configuring the Input Filters
