York MILLENNIUM YCAR0315 - TABLE 3 - Condenser Fan Control and Fan Contactor Data for DXRT Units with 3 Fans; System; TABLE 4 - Condenser Fan Control and Fan Contactor Data for DXRT Units with 4 Fans; System; TABLE 5 - Condenser Fan Control and Fan Contactor Data for DXRT Units with 5 Fans; System

149
YORK INTERNATIONAL
FORM 150.52-NM2 (1001)
Fan
ON OFF
Fan Wire
Relay
Stage
Fans Conditions Conditions
Contactor Number
Board
DP DP and OAT
Output
1 1 >15.2 BAR <10.3 BAR and <15.6°C 9M 130 15
S
2 3, 5 >16.2 BAR <11.4 BAR and <18.3°C 10M, 11M 131 14
Y
3 7, 9 >17.2 BAR <12.4 BAR and <21.1°C 12M, 13M 132 10
S
4 1, 7, 9 >18.3 BAR <13.4 BAR and <23.9°C 9M, 12M, 13M 130, 132 10,15
5 3, 5, 7, 9 >19.3 BAR <14.5 BAR and <26.7°C 10M, 11M, 12M, 13M 131, 132 10, 14
1
6 1, 3, 5, 7, 9 >20.0 BAR <15.2 BAR and <29.4°C 9M, 10M, 11M, 12M, 13M 130, 131, 132 10, 14, 15
1 2 >15.2 BAR <10.3 BAR and <15.6°C 15M 230 15
S
2 4, 6 >16.2 BAR <11.4 BAR and <18.3°C 16M, 17M 231 14
Y
3 8, 10 >17.2 BAR <12.4 BAR and <21.1°C 18M, 19M 232 10
S
4 2, 8, 10 >18.3 BAR <13.4 BAR and <23.9°C 15M, 18M, 19M 230, 232 10,15
5 4, 6, 8, 10 >19.3 BAR <14.5 BAR and <26.7°C 16M, 17M, 18M, 19M 231, 232 10, 14
2
6 2, 4, 6, 8, 10 >20.0 BAR <15.2 BAR and <29.4°C 15M, 16M, 17M, 18M, 19M 230, 231, 232 10, 14, 15
TABLE 5 – CONDENSER FAN CONTROL and FAN CONTACTOR DATA FOR DXRT UNITS WITH
5 FANS/SYSTEM (YCAR 0575, 0645 AND 0685)
TABLE 3 – CONDENSER FAN CONTROL AND FAN CONTACTOR DATA FOR DXRT UNITS WITH
3 FANS/SYSTEM (YCAR 0315, 0345, 0365 AND 0385)
Fan
ON OFF
Fan Wire
Relay
Stage
Fans Conditions Conditions
Contactor Number
Board
DP DP and OAT
Output
1 1 >15.2 BAR <10.3 BAR and <15.6°C 9M 130 15
S
2 3 >16.2 BAR <11.4 BAR and <18.3°C 10M 131 14
Y
3 5 >17.2 BAR <12.4 BAR and <21.1°C 11M 132 10
S
4 1, 5 >18.3 BAR <13.4 BAR and <23.9°C 9M, 11M 130, 132 10,15
5 3, 5 >19.3 BAR <14.5 BAR and <26.7°C 10M, 11M 131, 132 10, 14
1
6 1, 3, 5 >20.0 BAR <15.2 BAR and <29.4°C 9M, 10M, 11M 130, 131, 132 10, 14, 15
1 2 >15.2 BAR <10.3 BAR and <15.6°C 15M 230 15
S
2 4 >16.2 BAR <11.4 BAR and <18.3°C 16M 231 14
Y
3 6 >17.2 BAR <12.4 BAR and <21.1°C 17M 232 10
S
4 2, 6 >18.3 BAR <13.4 BAR and <23.9°C 15M, 17M 230, 232 10,15
5 4, 6 >19.3 BAR <14.5 BAR and <26.7°C 16M, 17M 231, 232 10, 14
2
6 2, 4, 6 >20.0 BAR <15.2 BAR and <29.4°C 15M, 16M, 17M 230, 231, 232 10, 14, 15
TABLE 4 – CONDENSER FAN CONTROL and FAN CONTACTOR DATA FOR DXRT UNITS WITH
4 FANS/SYSTEM (YCAR 0415, 0435, 0485 AND 0525)
Fan
ON OFF
Fan Wire
Relay
Stage
Fans Conditions Conditions
Contactor Number
Board
DP DP and OAT
Output
1 1 >15.2 BAR <10.3 BAR and <15.6°C 9M 130 15
S
2 3 >16.2 BAR <11.4 BAR and <18.3°C 10M 131 14
Y
3 5, 7 >17.2 BAR <12.4 BAR and <21.1°C 11M, 12M 132 10
S
4 1, 5, 7 >18.3 BAR <13.4 BAR and <23.9°C 9M, 11M, 12M 130, 132 10,15
5 3, 5, 7 >19.3 BAR <14.5 BAR and <26.7°C 10M, 11M, 12M 131, 132 10, 14
1
6 1, 3, 5, 7 >20.0 BAR <15.2 BAR and <29.4°C 9M, 10M, 11M, 12M 130, 131, 132 10, 14, 15
1 2 >15.2 BAR <10.3 BAR and <15.6°C 15M 230 15
S
2 4 >16.2 BAR <11.4 BAR and <18.3°C 16M 231 14
Y
3 6, 8 >17.2 BAR <12.4 BAR and <21.1°C 17M, 18M 232 10
S
4 2, 6, 8 >18.3 BAR <13.4 BAR and <23.9°C 15M, 17M, 18M 230, 232 10,15
5 4, 6, 8 >19.3 BAR <14.5 BAR and <26.7°C 16M, 17M, 18M 231, 232 10, 14
2
6 2, 4, 6, 8 >20.0 BAR <15.2 BAR and <29.4°C 15M, 16M, 17M, 18M 230, 231, 232 10, 14, 15
9
