York MILLENNIUM YCAR0315 User Manual

54
YORK INTERNATIONAL
FORM 150.52-NM2 (1001)
Technical Data
ELECTRICAL DATA
MULTIPLE POINT POWER SUPPLY CONNECTION (See Fig. 14)
(Each of Two Field Provided Power Supply Circuits individually protected with Branch Circuit Protection.
Field Connections to Factory provided Terminal Block (Std), Disconnects (Opt), or Breakers (opt) in each of the two Motor Control Centers.)
SYSTEM #1 FIELD-SUPPLIED WIRING
CHILLER
MODEL
VOLTS MIN NF
FACTORY PROVIDED (LUGS) WIRE RANGE
7
COMPRESSOR FANS
11, 12
YCAR MCA
1
DISC SW
2
STD. TERMINAL OPTIONAL NF.
OPT. CIRCUIT BRKR. RLA PW-LRA X-LRA QTY
FLA LRA
MIN.
3, 5
MAX.
4, 6
BLOCK DISC SWITCH
(EA.) (EA.)
YCAR0315 380 126.9 200 150 200 6 AWG to 1/0 AWG (1)4-300KCM (1)4AWG-300KCM 92 360 463 3 3.8 19.0
YCAR0345 380 158.1 200 200 250 2 AWG to 4/0 AWG (1)4-300KCM (1)4AWG-300KCM 117 461 585 3 3.8 19.0
YCAR0365 380 158.1 200 200 250 2 AWG to 4/0 AWG (1)4-300KCM (1)4AWG-300KCM 117 461 585 3 3.8 19.0
YCAR0385 380 175.6 200 225 300 2 AWG to 4/0 AWG (1)6-350KCM (1)4AWG-300KCM 131 519 641 3 3.8 19.0
YCAR0415 380 179.4 200 225 300 2 AWG to 4/0 AWG (1)6-350KCM (1)4AWG-300KCM 131 519 641 4 3.8 19.0
YCAR0435 380 220.7 250 300 350 2 AWG to 300 MCM (1)6-350KCM (2)3/0-250KCM 164 639 801 4 3.8 19.0
YCAR0485 380 220.7 250 300 350 2 AWG to 300 MCM (1)6-350KCM (2)3/0-250KCM 164 639 801 4 3.8 19.0
YCAR0525 380 250.7 250 300 400 1/0 AWG to 500 MCM (1)6-350KCM (2)3/0-250KCM 188 639 801 4 3.8 19.0
YCAR0575 380 251.0 250 350 400 1/0 AWG to 500 MCM (1)6-350KCM (2)3/0-250KCM 188 639 801 5 3.8 19.0
YCAR0645 380 304.5 400 400 500 1/0 AWG to 500 MCM (2)3/0-250KCM (2)3/0-250KCM 228 910 1173 5 3.8 19.0
YCAR0685 380 304.5 400 400 500 1/0 AWG to 500 MCM (2)3/0-250KCM (2)3/0-250KCM 228 910 1173 5 3.8 19.0
OVER-CURRENT
PROTECTION
FIELD PROVIDED POWER SUPPLY
See page 53 for Electrical Data footnotes.
