WEIGHT DISTRIBUTION AND ISOLATOR MOUNT POSITIONS
ALUMINUM FIN CONDENSER COILS
TYPE & SIZE
MAX. LOAD DEFL.
lbs. kg in. mm
AWMR-1-53 1000 453.6 2 51
AWMR-1-530 1150 521.6 2 51
AWMR-1-531 1276 578.8 2 51
AWMR-1-532 1500 680.4 2 51
AWMR-1-551 1676 760.2 2 51
AWMR-1-552 1900 861.8 2 51
AWMR-1-553 2200 997.9 2 51
AWMR-2-531 2552 1157.6 2 51
AWMR-2-532 3000 1360.8 2 51
ALUMINUM FIN COIL 1" DEFL. ISOLATOR SELECTION / LOCATION
VMC TYPE CP-2-XX (See Table Above)
YCAR A B C D E F G H
0315 27 27 28 27 28 28 — —
0345 27 27 28 27 28 28 — —
0365 27 27 28 27 28 28 — —
0385 27 27 28 27 28 28 — —
0415 28 27 27 26 28 27 27 27
0435 28 27 27 26 28 27 27 27
0485 27 27 27 26 28 28 27 27
0525 27 27 27 26 28 28 27 27
0575 31 28 27 26 31 31 28 27
0645 31 28 27 26 31 31 28 27
0685 31 28 27 26 31 31 28 27
TYPE & SIZE
MAX LOAD DEFL. SPRING
lbs. kg in. mm COLOR
CP-2-26 1200 544.3 1.17 29.7 Purple
CP-2-27 1500 680.4 1.06 26.9 Orange
CP-2-28 1800 816.4 1.02 25.9 Green
CP-2-31 2200 997.9 0.83 21.0 Gray
CP-2-32 2600 1179.3 0.74 18.7 White
CP-2-35 3000 1360.8 0.70 17.7 Gold
ALUMINUM FIN COIL, 2" DEFL. ISOLATOR SELECTION / LOCATION
VMC TYPE AWMR-X-XXX (See Table Below)
YCAR A B C D E F G H
0315 -1-532 -1-532 -1-551 -1-532 -1-551 -1-552 — —
0345 -1-532 -1-532 -1-551 -1-532 -1-551 -1-552 — —
0365 -1-532 -1-532 -1-551 -1-532 -1-551 -1-552 — —
0385 -1-532 -1-532 -1-551 -1-532 -1-551 -1-552 — —
0415 -1-532 -1-532 -1-531 -1-530 -1-551 -1-532 -1-532 -1-530
0435 -1-532 -1-532 -1-531 -1-530 -1-551 -1-532 -1-532 -1-530
0485 -1-551 -1-532 -1-532 -1-532 -1-552 -1-551 -1-532 -1-532
0535 -1-551 -1-532 -1-532 -1-532 -1-552 -1-551 -1-532 -1-532
0575 -1-552 -1-551 -1-532 -1-531 -1-531 -1-552 -1-551 -1-532
0645 -1-552 -1-551 -1-532 -1-531 -1-531 -1-552 -1-551 -1-532
0685 -1-552 -1-551 -1-532 -1-531 -1-531 -1-552 -1-551 -1-532
