Zanotti un0 080 - 5.3 Digital Sensors

1
36
Electronics and wiring
5.2 Electronic Boards
J1 & J2 Cab Command ports
J6 Power Supply port
Pin Wire From
J1 Red
Cab
C.
J1 Blue
Cab
C.
J2+ Brow
n Cab C.
J2- Black Cab C.
J2 sig Orange Cab C.
Pin Wire From
-
NE196 J19 - pin6
+ RED +
-
+
