Electronics and wiring
5.2 Electronic Boards
J10 Pwr Board Ground Port
J12 Pwr Board Port
Pin Wire From
1 -
-
2 NE102 SA
3 NE103 FMI, FM1S
4 NE104 FTQ
5 NE105 ON/OFF
6 NE106 PMX
7 NE107 FTS1-2
8 NE108 MP
9 -
-
10 NE1010 PMI
11 -
-
12 NE1012 KSF
Pin Wire From/To
1 80
YS
2 2
2
YAV
3 18
Fuel
Valve
4 1
6
PN
5 16
Emergency Bo
ard
6 NE1
26 YS
7 NE127 YAV
8 NE128 Fuel Valve
9 NE129 PN
10 NE121O Emergency Board
