Zanotti un0 080 - Top Door Access; Bottom Cover Access

25
2.1 Condensing unit
Description of the unit
Top door Access
1. LP service port 3.3.2 Section
2. Liquid line shut-off valve
3. Filter Drier and Sight Glass 3.
4
Section
4. HPL servic
e port 3.3.2
Section
5. CPR Crankcas
e Pressure Regulation Valve 3.6
Section
6. KVC Hot Gas Bypass Capacity Regulator 3.7 Se
ct
ion
7. MP Unit Door Micro-s
witch 5.3.6 Sect
ion
8. Stand-by Com
pressor 3.9
Section
9. Road Comp
ressor 3.10 Sectio
n
10
. Expansion Tank 5.3.2 Sect
ion
11
. Engine Devices 5.6.4 Sect
ion
12
. Oil Filter 5.2.1 Sect
ion
13
. Oil Pressure Switch 5.3.4
Section
14
.
Oil filler cap
Bottom cover access
(j) Unscrew right side cover. (k) Slide and pull back removing left side
cover.
(l) Pull front cover forth just enough to
release unit bottom.
Main accessible parts:
1) Oil Sump
2) Components Fixing Screws
