Zanotti un0 080 - Driver-Left Side Access

24
Description of the unit
2.1 Condensing unit
Main accessible parts:
1) Servic
e Ports 3.3.2 Sect
ion
2) Check Valves 3.3.4 Section
3) Filter Drier 3.4 Section
4) 3-ways sole
noid Valve 3.3.3.3 Sect
ion
5) PMI Lo
w Pressure Switch 5.3.3.1 Sect
ion
6) PMX High Pressure Switch 5
.3.3.2 Sect
ion
7) P1MX Co
ndenser Fan Switch 5.3.3.3 Sect
ion
8) SA Diff
erential Air Switch 5.3.1
Section
9) Liquid Receiver Shut-off Valve 3.3.1 Se
ct
ion
Driver-Left Side Access
Left side cover gives access to Air and Fuel Filters, Engine Service Belts, Alternator.
(h) Unscrew right side cover. (i) Slide and pull back removing left side cover.
Main accessible parts:
1. Air Filter 5.4.3 Sect
ion
2. Fuel Filter 5.4.1 Se
ct
ion
3. Engine s
ervice belts 5.1
Section
4. ALT Alternator 5.5.1 Se
ct
ion
