General information
1.3 Safety precautions
Unit Diesel Engine Road Mode Compressor
un0°060 3CA1 FK20/170
un0°080 3CA1 FK30/235
un0°100 3CB1 FK30/325
un0°120 3CB1 FK40/390
T
able 1.2.2: T(400V/3/50Hz) Stand-By Configurations
Unit Stand-by Compressor Absorption [A]
Max Abs. [A] Inrush Current [A]
un0°060 ZF11 6, 84 7, 73 46
un0°080 ZF13 7, 71 9, 73 51.5
un0°100 ZF15 9.58 11.73 64
un0°120 ZF11 6, 84 7, 73 46
T
able 1.2.3: B(230V/3/60Hz) Stand-By Configurations
Unit Stand-by Compressor Absorption [A]
Max Abs. [A] Inrush Current [A]
un0°060 ZF09 10.68 13 77
un0°080 ZF13 12.5 16 99
un0°100 ZF13 12.5 16 99
T
able 1.2.4: C(400V/3/60Hz) Stand-By Configurations
Unit Stand-by Compressor Absorption [A]
Max Abs. [A] Inrush Current [A]
un0°120 ZF15 9.89 12 64
Table 1.2.5: H(208V/3/60Hz) Stand-By Configurations
Unit Stand-by Compressor Absorption [A]
Max Abs. [A] Inrush Current [A]
un0°080 ZF13 12.5 16 99
un0°100 ZF13 12.5 16 99
T
able 1.2.6: N(208V/1/60Hz) Stand-By Configurations
Unit Stand-by Compressor Absorption [A]
Max Abs. [A] Inrush Current [A]
un0°080 ZF11 11, 3 20, 7 109
Table 1.2.7: P(220V/1/60Hz) Stand-By Configurations
Unit Stand-by Compressor Absorption [A]
Max Abs. [A] Inrush Current [A]
un0°080 ZF11 11, 3 20, 7 109
1.3 Safety precautions
General notices
Most accidents are caused by negligence of basic safety rules and precautions. Please read this manual carefully to fully
understand the safety precautions and correct procedures before starting a repair, maintenance or inspection operation.
Transport refrigeration unit maintenance requires careful attention to safety precautions for proper vehicle and engine
upkeep. Other risks comes from the pressurized refrigerant inside cooling circuit and the electrical connections.
PPE Personal Protective Equipment (in accordance with 89/686/EEC)
Personal protective equipment PPE like steel toed shoes and protective eye-wear are designed to protect wearer’s body from
injuries. The purpose of PPE is to reduce hazards, protecting from injuries or reducing their magnitude, but the only way to
