SET OPTIONS
Parameter Allowable range Description
MAIN POT. TYPE
(T, TM)
0 ÷ 11 This parameter decides the feature of the main
potentiometer, connected to pin A15.
#
Pot.
type
Low to High /
High to Low
Direction
switches
Enable
switch
En. dead
band
0 V-type L to H X
1 V-type L to H X X
2 V-type H to L X
3 V-type H to L X X
4 Z-type L to H X
5 Z-type L to H X X
6 Z-type L to H X X
7 Z-type L to H X
8 Z-type H to L X
9 Z-type H to L X X
10 Z-type H to L X X
11 Z-type H to L X
AUX POT. TYPE
(T, TM, P)
0 ÷ 12 This parameter decides the type of the auxiliary
potentiometer, connected to pin A30.
#
Pot.
type
Low to High /
High to Low
Direction
switches
Enable
switch
En. dead
band
0
÷
11
Same as MAIN POT. TYPE,
see previous parameter.
12 No H to L X X
13
÷
1
5
For
future
uses
13
÷ 15
For
future
uses
13
÷
1
5
For
future
uses
SET MOT.TEMPERAT
(T, TM, P, CO)
NONE ÷ OPTION#2 Sets the motor temperature sensor type.
NONE = no motor thermal sensor switch is connected.
DIGITAL = a digital (ON/OFF) motor thermal sensor is
connected to A22.
OPTION#1 = an analogue motor thermal sensor is
connected to A22. The temperature sensor is a KTY
84-130 PTC (positive thermal coefficient resistance).
OPTION#2 = an analogue motor thermal sensor is
connected to A22. The temperature sensor is a KTY
83-130 PTC (positive thermal coefficient resistance)
OPTION#3 = an analog motor thermal sensor is
connected to A22. The temperature sensor is a PT1000
PTC (positive thermal coefficient resistance).
