Accessories 10 - 9
Communication
Insert the MC67 into the slot to initiate communication over an Ethernet network. The LEDs on the front of the
cradle indicate the speed and activity of the connection.
LED Indicators (CRD5500-4000ER)
There are two LEDs on the front of the cradle. The green Speed LED lights to indicate that the transfer rate is
100 Mbps. When the LED is not lit the transfer rate is 10 Mbps. The yellow Link LED blinks to indicate activity,
or stays lit to indicate that a link is established. When it is not lit it indicates that there is no link.
LED Indicators (CRD5501-4000ER)
There are two green LEDs on the front of the cradle. These green LEDs light and blink to indicate the data
transfer rate. When the LEDs are not lit the transfer rate is 10 Mbps.
Table 10-3
CRD5500-4000ER LED Data Rate Indicators
Data Rate Green Speed LED (Left) Yellow Link LED (Right)
100 Mbps On On/Blink
10 Mbps Off On/Blink
Table 10-4
CRD5501-4000ER LED Data Rate Indicators
Data Rate Left LED (Green) Right LED (Green)
1 Gbps On/Blink Off
100 Mbps Off On/Blink
10 Mbps Off Off
