Bluetooth 7 - 29
1. Ensure the MC67 is connectable (required when automatic re-connect is initiated). See Device Info on
page 7-34.
2. Ensure that the Headset profile is enabled on the MC67. See Profiles on page 7-41 for more information.
3. Use the Connection Wizard to search for a Bluetooth headset.
4. Select the device and tap Next.
5. Select the Headset service name and select Connect. The MC67 connects to the headset. Refer to the
headset user manual for instructions on communicating with a Bluetooth device.
6. Press the communication button on the headset. This routes both system and WAN call audio to the
headset.
7. When a call is received on the MC67, tap the Accept button to answer the call.
8. Press the communication button on the headset to route the audio back to the MC67.
Serial Port Services
Use the wireless Bluetooth serial port connection as a physical serial cable connection. Configure the
application that will use the connection to the correct serial port.
To establish a serial port connection:
1. Use the Connection Wizard to search for a Bluetooth serial device.
2. Select the device and tap Next. The Connection Favorite Options window appears.
3. In the Local COM Port: drop-down list select a COM port.
4. Tap Finish.
ActiveSync Using Serial Port Services
Use the wireless Bluetooth serial port connection for ActiveSync just as a physical serial cable connection.
Configure the application that will use the connection to the correct serial port.
NOTE Newer Bluetooth headsets are device dependant and remember the last device they connected to. If
problems occur while connecting to the headset, place the headset in discovery mode. Refer to the
headset user manual for more information.
NOTE When using a Bluetooth headset with Headset Services, the user cannot accept or end a call from the
headset. The user must accept or end a call on the MC67.
NOTE By default, COM ports COM5, COM9, COM11, COM21, COM22 and COM23 are Bluetooth virtual ports.
If an application opens one of these ports, the Bluetooth driver activates and guides the user through a
Bluetooth connection.

Zebra MC67 Specifications

General

Display diagonal	3.5 \
Display resolution	640 x 480 pixels
Display number of colors	-
Flash memory	2 GB
Internal memory	0.512 GB
Internal memory type	RAM
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	32 GB
Processor family	Instruments OMAP
Processor frequency	0.8 GHz
Processor manufacturer	Texas Instruments
USB 2.0 ports quantity	1
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Battery capacity	3600 mAh
Data network	4G, HSPA+
Wi-Fi standards	802.11a, 802.11b, 802.11g
Product color	Black
Keyboard layout	QWERTY
Operating system installed	Windows Mobile 6.5

Weight and Dimensions

Depth	33.5 mm
Width	77 mm
Height	162.2 mm
Weight	385 g
