Zebra MC67 User Manual

Technical Specifications A - 5
Skew Tolerance +/- 60° from normal
Ambient Light Indoor: 450 ft. candles (4845 lux)
Outdoor: 9000 ft. candles (96,900 lux)
Sunlight: 8000 ft. candles
Fluorescent: 450 ft. candles
Focal Distance From center of exit window: 18.5 cm (7.3 in.)
Aiming Element (VLD) 655 nm +/- 10 nm
Illumination Element (LED) 625 nm +/- 5 nm
Camera Specifications
Resolution 8 Mega pixel
Table A-2 Data Capture Supported Symbologies
Item Description
1D Bar Codes Chinese 2 of 5 Codabar Code 11
Code 128 Code 39 Code 93
Coupon Code Discrete 2 of 5 EAN-8
EAN-13 GS1 DataBar GS1 DataBar 14
GS1 DataBar Expanded GS1 DataBar Expanded Stacked
GS1 DataBar Limited Interleaved 2 of 5 ISBT 128
Korean 2 of 5 Matrix 2 of 5 MSI
TLC39 Trioptic 39 UCC/EAN 128
UPCA UPCE UPCE1
UPC/EAN Supplementals Webcode
2D Bar Codes Australian Postal Aztec Canadian Postal
Composite AB Composite C Data Matrix
Dutch Postal Japanese Postal Linked Aztec
Maxi Code Micro PDF-417 microQR
PDF-417 QR Code US Planet
UK Postal US Postnet USPS 4-state (US4CB)
Table A-1 MC67 Technical Specifications (Continued)
Item Description

Zebra MC67 Specifications

General

Display diagonal	3.5 \
Display resolution	640 x 480 pixels
Display number of colors	-
Flash memory	2 GB
Internal memory	0.512 GB
Internal memory type	RAM
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	32 GB
Processor family	Instruments OMAP
Processor frequency	0.8 GHz
Processor manufacturer	Texas Instruments
USB 2.0 ports quantity	1
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Battery capacity	3600 mAh
Data network	4G, HSPA+
Wi-Fi standards	802.11a, 802.11b, 802.11g
Product color	Black
Keyboard layout	QWERTY
Operating system installed	Windows Mobile 6.5

Weight and Dimensions

Depth	33.5 mm
Width	77 mm
Height	162.2 mm
Weight	385 g
