Zebra RFD8500 User Manual

3 - 8 RFD8500 User Guide
Settings
Touch Settings from the Home or Menu screen.
Figure 3-5 Settings Screen
Table 3-2 Settings Screen Options
Settings Option Description Page
Readers List Displays all previous and new RFD8500 readers with which the
mobile device paired.
3-9
Application Displays reader connection, notification, and data export
settings.
3-10
Antenna Displays antenna power lever and link profile. 3-11
Singulation Control Displays Session, Tag Population, Inventory State and SL Flag. 3-12
Start\Stop Triggers Allows START and STOP button control. 3-13
Tag Reporting Displays 3-14
Regulatory Allows region and channel selections. 3-16
Battery Displays the RFD8500 battery status. 3-17
Power Management Turns Dynamic Power Optimization on and off. 3-18
Beeper Use to turn the beeper on/off, and set volume. 3-19
Save Configuration Allows the user to save all settings: Antenna, Singulation, Tag
Reporting, START/STOP trigger, Beeper Volume, and
Regulatory.
Note: The settings are also automatically saved
when the user changes anything.
3-20

Zebra RFD8500 Specifications

General

Type	Handheld bar code reader
Sensor type	-
Scanner type	1D/2D
Read rate (max)	600 reads/s
Bluetooth version	2.1+EDR
Operating frequency	865 - 868 MHz
Standard interfaces	Bluetooth
Product color	Gray
LED indicators	Yes
Protection features	Dust resistant, Splash proof
Battery capacity	4410 mAh
Power source type	Battery
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-10 - 40 °C
Operating relative humidity (H-H)	5 - 85 %
Mobile operating systems supported	Android 4.4, Android 5.0, Android 5.1, iOS 8.0, iOS 8.2, iOS 9.0
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	130 mm
Width	185 mm
Height	80 mm
Weight	430 g
