5 - 6 RFD8500 User Guide
Active Scanner Screen
This screen displays information about the connected scanner and includes three tabs: INFO, BARCODE, and
SETTINGS.
Figure 5-7 Active Scanner Screen - INFO, BARCODE, SETTINGS Tabs
INFO
Touch INFO to access the INFO tab. The INFO tab provides information about the connected scanner and
allows the user input detailed in Table 5-1.
Table 5-1 Active Scanner Screen - INFO Tab
Field Description
Disconnect Touch Disconnect to disconnect the scanner from the mobile
computer.
ID Unique identifier of the scanner assigned by the SDK.
NAME Name and serial number of the scanner.
Asset Information Touch Asset Information to display the scanner’s:
• Model
• Serial number
• Firmware version
• Date of Manufacture
• Configuration.

Zebra RFD8500 Specifications

General

Type	Handheld bar code reader
Sensor type	-
Scanner type	1D/2D
Read rate (max)	600 reads/s
Bluetooth version	2.1+EDR
Operating frequency	865 - 868 MHz
Standard interfaces	Bluetooth
Product color	Gray
LED indicators	Yes
Protection features	Dust resistant, Splash proof
Battery capacity	4410 mAh
Power source type	Battery
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-10 - 40 °C
Operating relative humidity (H-H)	5 - 85 %
Mobile operating systems supported	Android 4.4, Android 5.0, Android 5.1, iOS 8.0, iOS 8.2, iOS 9.0
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	130 mm
Width	185 mm
Height	80 mm
Weight	430 g
