Zebra RFD8500 User Manual

3 - 18 RFD8500 User Guide
Power Management
Figure 3-14 Settings - Power Management
This screen provides an option to enable dynamic power optimization (DPO) in the reader. Enabling DPO
enhances battery life when performing inventory operations.
If Dynamic Power is on, a green battery icon appears in the title bar of the application. Clicking on this opens
the Battery Status screen.
NOTE DPO is enabled by default. With DPO enabled, access operations and filters/singulation setting changes
do not take effect.

Zebra RFD8500 Specifications

General

Type	Handheld bar code reader
Sensor type	-
Scanner type	1D/2D
Read rate (max)	600 reads/s
Bluetooth version	2.1+EDR
Operating frequency	865 - 868 MHz
Standard interfaces	Bluetooth
Product color	Gray
LED indicators	Yes
Protection features	Dust resistant, Splash proof
Battery capacity	4410 mAh
Power source type	Battery
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-10 - 40 °C
Operating relative humidity (H-H)	5 - 85 %
Mobile operating systems supported	Android 4.4, Android 5.0, Android 5.1, iOS 8.0, iOS 8.2, iOS 9.0
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	130 mm
Width	185 mm
Height	80 mm
Weight	430 g
