Zebra TC52 Integrator Guide

Accessories
28
4-Slot Charge Only Cradle with Battery Charger
CAUTION: Ensure that you follow the guidelines for battery safety described in Battery Safety Guidelines on page 169.
The 4-Slot Charge Only Cradle with Battery Charger:
• Provides 5 VDC power for operating the device.
• Simultaneously charges up to four devices and up to four spare batteries using the Battery Charger
Adapter.
Figure 15 4-Slot Charge Only Cradle with Battery Charger Setup
Charging the Device
To charge a device:
NOTE: If the device has a Rugged Boot, remove the cup insert before inserting the device. By default, the device includes
an interface connector. If the interface connector is removed for USB Type C cable connectivity, then it must be replaced
before charging or receiving an Ethernet IP address if placed in a cradle.
1. Insert the device into the slot to begin charging.
AC Line Cord
DC Line Cord
Power Supply

Zebra TC52 Specifications

General

RFID reader	-
Scanner type	2D
Product color	Black
Phone function	Yes
Display diagonal	5 \
Touch technology	Dual-touch
Touchscreen type	Capacitive
Display resolution	1280 x 720 pixels
USB 2.0 ports quantity	1
Flash memory	32 GB
Internal memory	4 GB
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	256 GB
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Battery capacity	4150 mAh
Number of cores	8
Processor model	660
Processor family	Snapdragon
Processor frequency	2.2 GHz
Processor manufacturer	Qualcomm
GPS (satellite)	No
Operating system installed	Android
Bluetooth version	5.0
Rear camera aperture number	2.2
Front camera aperture number	2
Rear camera resolution (numeric)	13 MP
Front camera resolution (numeric)	5 MP

Weight and Dimensions

Depth	18.6 mm
Width	75.5 mm
Height	155 mm
Weight	249 g
