Zebra TC52 - Rack Mount Installation

Accessories
53
Figure 49 Connect Cables
11.Secure top tray to bottom tray with four M5 screws (two on each side).
Figure 50 Secure Top Tray to Bottom Tray
See Rack Mount Installation on page 53 for installing the bracket onto a rack.
Rack Mount Installation
NOTE: Use screws provided with rack system. Refer to rack user documentation for instructions.
