DataWedge
82
Code ID Type - A Code ID character identifies the code type of a scanned barcode. This is useful when the
reader is decoding more than one code type. Select a code ID character to insert between the prefix and
the decoded symbol.
Code ID Type None - No prefix (default)
Code ID Type AIM - Insert AIM Character prefix.
Code ID Type Symbol - Insert Symbol character prefix.
Engine Decode LED - Use to turn on scanner red LED when the scan beam is emitting either by scanner
trigger or using soft scan button.
BT Disconnect On Exit - Bluetooth connection is disconnected when data capture application is closed .
Connection Idle Time - Set connection idle time. The Bluetooth connection disconnects after being idle for
set time.
Display BT Address Barcode - Enable or disable displaying Bluetooth Address bar code if there is no
Bluetooth scanner being paired when application tries to enable the Bluetooth scanner.
Establish Connection Time - The timeout which the device will try to enable or reconnect to the Bluetooth
scanner when the Bluetooth scanner is not in the vicinity or not paired.
Audio Feedback Mode - Select good decode audio indication.
Local Audio Feedback - Good decode audio indication on device only.
Remote Audio Feedback - Good decode audio indication.
Both - Good decode audio indication on device and scanner (default).
Disable - No good decode audio indication on either device or scanner.
LED Feedback Mode - Select good decode LED indication.
Local LED Feedback - Good decode LED indication on device only.
Remote LED Feedback - Good decode LED indication on scanner.
Both - Good decode LED indication on device and scanner (default).
Disable - No good decode LED indication on either device or scanner.
Decode Audio Feedback - Select an audio tone to sound upon a good decode (default optimized-beep).
Decoding LED Notification - Enable the device to light the red Data Capture LED when data capture is in
progress. (default - disabled).
Decode Feedback LED Timer
- Set the amount of time (in milliseconds) that the green Data Capture LED
stays lit after a good decode. (default - 75 msec.)
Beep Volume Control - Set the good decode beep to a system or other sound. This allows for independent
control of the good beep volume.
NOTE: Not all ringtones are fully supported as decode tones and those of longer length may be truncated when used as a
decode tone. The recommendation is to test the selected tone for operation before deployment to a customer site.
Ringer - Set the good decode beep to the ringer sound.
Music and Media - Set the good decode beep to the media sound.
Alarms - Set the good decode beep to the alarm sound.
Notifications - Set the good decode beep to the notification sound (default).
UDI Params
Allows the configuration of parameters specific to healthcare barcodes.
Enable UDI-GSI - Enable UDI using GS1 standards (default - enabled).
Enable UDI-HIBCC - Enable UDI using HIBCC standards (default - enabled).
