Zebra TC77 User Manual

227
Storage Temperature -40°C to 70°C (-40°F to 158°F)
Charging Temperature 0° C to 40° C (32°F to 104°F)
Humidity 5 to 95% non-condensing
Drop Specification 8 ft./2.4 m to concrete at room temperature; 6 ft./1.8 m over the operating
temperature range
Tumble 2,000 3.2 ft./1.0 m tumbles; meets and exceeds IEC tumble specifications
Electrostatic Discharge (ESD) +/-15kVdc air discharge, +/-8kVdc direct discharge, +/-8kVdc indirect
discharge
Sealing IP65 and IP67 per applicable IEC sealing specifications
Vibration 4 g’s PK Sine (5 Hz to 2 kHz); 0.04g2/Hz Random (20 Hz to 2 kHz); 60
minute duration per axis, 3 axis
Thermal Shock -40° C to 70° C (-40° F to 158° F) rapid transition
Interactive Sensor Technology (IST)
Motion Sensor 3-axis accelerometer provides motion-sensing for dynamic screen orientation
and power management
Light Sensor Ambient light sensor to auto adjust display backlight brightness
Atmospheric Pressure Sensor Available on TC77 only.
Wireless WAN Data and Voice Communications (TC77 only)
Frequency band Supports VoLTE, Carrier Aggregation up to 3DL CA
LTE FDD: 700/800/850/900/1800/1900/AWS/2100/2600
(28,13,14,12,17/19,20/5,26/8/3/2,25/4,66/1/7);
LTE TDD: 1900/2300/2500 (39/40/41,38);
UMTS/HSPA/HSPA+: 850/900/AWS/1900/2100 (5/8/4/2/1);
GSM/GPRS/EDGE: 850/900/1800/1900
GPS Integrated, Autonomous, Assisted GPS (A-GPS), Navstar, GLONASS,
BeiDou, Galileo
Wireless LAN Data and Voice Communications
Radio
IEEE 802.11 a/b/g/n/ac/d/h/i/r/k/v
3
/w; Wi-Fi ™ certified; IPv4, IPv6, 2x2
MU-MIMO
Data Rates Supported 5 GHz: 802.11a/n/ac - up to 866.7 Mbps
2.4 GHz: 802.11b/g/n - up to 300 Mbps
Operating Channels Channel 1 - 13 (2412 - 2472 MHz); Chan 36 - 165 (5180 - 5825 MHz)
Channel Bandwidth: 20, 40, 80 MHz
Actual operating channels/frequencies and bandwidths depend on regulatory
rules and certification agency.
Security WEP (40 or 104 bit); WPA/WPA2 Personal (TKIP, and AES); WPA/WPA2
Enterprise (TKIP and AES) - EAP-TTLS (PAP, MSCHAP, MSCHAPv2),
EAP-TLS, PEAPv0-MSCHAPv2, PEAPv1-EAP-GTC and LEAP.EAP-PWD
Table 23 Device Technical Specifications (Continued)
Item Description

Zebra TC77 Specifications

General

Display diagonal	4.7 \
Touch technology	Dual-touch
Touchscreen type	Capacitive
Display resolution	1280 x 720 pixels
Flash memory	32 GB
Internal memory	4 GB
Internal memory type	-
Compatible memory cards	MicroSD (TransFlash), SD, SDHC, SDXC
Number of cores	8
Processor family	Snapdragon
Processor frequency	2.2 GHz
Processor manufacturer	Qualcomm
Operating system version	8.1
Operating system installed	Android
Data network	2G, 3G, EDGE, GPRS, HSPA, HSPA+, LTE, UMTS
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version	5.0
GSM bands supported	850, 900, 1800, 1900 MHz
Security algorithms	AES, EAP-TTLS, LEAP, MSCHAPv2, PEAP, TKIP, WEP, WPA, WPA-Enterprise, WPA2, WPA2-Enterprise
Rear camera resolution (numeric)	13 MP
USB 2.0 ports quantity	1
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Battery voltage	3.7 V
Battery capacity	4620 mAh
Certification	WFA (802.11n, WMM-PS, 801.11ac, PMF)
Product color	Black, Silver
Linear (1D) barcodes supported	Code 39
International Protection (IP) code	IP65, IP68
Harmonized System (HS) code	84713000

Weight and Dimensions

Depth	28 mm
Width	84 mm
Height	161 mm
Weight	376 g
