Zebra TC77 User Manual

228
Voice Communications Wi-Fi Multimedia (WMM), Soft AP, MIMO with 2 Spatial Streams, 256 QAM
Modulation on 5G GHz radio; Maximum Ratio Combining (MRC), Tx/Rx
Low-Density Parity Check (LDPC), Transmit Beamforming (TxBF) and
Beamformee (BFee) capability, Full IEEE 802.11 a/b/g/n legacy compatibility
Wireless PAN Data and Voice Communications
Bluetooth Class 2, Bluetooth v5.0, Bluetooth Low Energy (BLE)
Data Capture Specifications
2D Imager SE4750-SR – 1D and 2D barcodes.
Camera Rear: 13 Mega pixel auto focus with flash
Front: 5 Mega pixel fixed focus
Near Field Communications
(NFC)
ISO 14443 Type A and B; F; FeliCa and ISO 15693 cards; P2P mode and
Card Emulation via Host.
SAM support for Calypso, Felica, and Mifare technology.
Dual SAM support on TC77
Communication and Messaging
Workforce Connect PTT Express (included) provides instant push-to-talk (PTT) small group communications
across Wi-Fi networks. Workforce Connect PTT Pro (supported) provides a scalable network agnostic
push-to-talk solution which also includes messaging, location services and two-way radio integration. Workforce
Connect Voice client (supported) enables the device to function as a full featured mobile telephone with
multi-line capability across Wi-Fi networks.
2D Imager Engine (SE4750-SR) Specifications
Field of View Horizontal - 48.0°
Vertical - 36.7°
Image Resolution 1280 horizontal X 960 vertical pixels
Roll 360°
Pitch Angle +/- 60° from normal
Skew Tolerance +/- 60° from normal
Ambient Light Sunlight: 10,000 ft. candles (107,639 lux)
Focal Distance From front of engine: 17.7 cm (7.0 in.)
Laser Aiming Element Visible Laser Diode (VLD): 655 nm +/- 10 nm
Central Dot Optical Power: 0.6 mW (typical)
Pattern Angle: 48.0º horizontal, 38.0º vertical
Illumination System LEDs: Warm white LED
Pattern Angle: 80° at 505 intensity
Table 23 Device Technical Specifications (Continued)
Item Description
Table 24 Data Capture Supported Symbologies
Item Description
1D barcodes Code 128, EAN-8, EAN-13, GS1 DataBar Expanded, GS1 128, GS1 DataBar
Coupon, UPCA, Interleaved 2 of 5, UPC Coupon Code
2D barcodes PDF-417, QR Code, Digimarc, Dotcode

Zebra TC77 Specifications

General

Display diagonal	4.7 \
Touch technology	Dual-touch
Touchscreen type	Capacitive
Display resolution	1280 x 720 pixels
Flash memory	32 GB
Internal memory	4 GB
Internal memory type	-
Compatible memory cards	MicroSD (TransFlash), SD, SDHC, SDXC
Number of cores	8
Processor family	Snapdragon
Processor frequency	2.2 GHz
Processor manufacturer	Qualcomm
Operating system version	8.1
Operating system installed	Android
Data network	2G, 3G, EDGE, GPRS, HSPA, HSPA+, LTE, UMTS
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version	5.0
GSM bands supported	850, 900, 1800, 1900 MHz
Security algorithms	AES, EAP-TTLS, LEAP, MSCHAPv2, PEAP, TKIP, WEP, WPA, WPA-Enterprise, WPA2, WPA2-Enterprise
Rear camera resolution (numeric)	13 MP
USB 2.0 ports quantity	1
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Battery voltage	3.7 V
Battery capacity	4620 mAh
Certification	WFA (802.11n, WMM-PS, 801.11ac, PMF)
Product color	Black, Silver
Linear (1D) barcodes supported	Code 39
International Protection (IP) code	IP65, IP68
Harmonized System (HS) code	84713000

Weight and Dimensions

Depth	28 mm
Width	84 mm
Height	161 mm
Weight	376 g
