INSTRUMENT DESCRIPTION
Axiovert 200 Technical Data Carl Zeiss
B 40-080 e 03/01 1-15
Line frequency......................................................................................................................50 to 60 Hz
Power consumption with internal power units
Axiovert 200...........................................................................................................................235 VA
Axiovert 200 M.......................................................................................................................235 VA
and external power units
Power supply N XBO 75, 100 ... 240 V AC...............................................................................130 VA
Power supply N HBO 100, 90 ... 240 V AC...............................................................................265 VA
Fuses in accordance with IEC 127
Axiovert 200
100 ... 240 V AC....................................................................................T 4.0 A/H; 250 V; 5 × 20 mm
Axiovert 200 M
100 ... 240 V AC....................................................................................T 4.0 A/H; 250 V; 5 × 20 mm
Light sources
HBO 50 W/AC mercury pressure short-arc lamp
Lamp voltage for lamp type L1 and L2....................................................L1: 39 ... 45 V/L2: 34 ... 39 V
Power........................................................................................................................................50 W
Average life...............................................................................................................................100 h
HBO 103 mercury vapor short-arc lamp.........................................................................................100 W
Opto-mechanical data
Stand with stage focusing............................................................................with coarse drive (5 mm/rot)
and fine drive (0.1 mm /rot)
Fine scaling 1 µm/scale part
Overall lift approx. 10 mm
Objective change................................................................................................via 6-position nosepiece
Objectives......................................................................................................with W 0.8" x 1/36"thread
Eyepieces .................................................................................................. with plug-in diameter 30 mm
and............................................................................................................................field number 23
