START-UP
Axiovert 200 Screw in objectives Carl Zeiss
B 40-080 e 03/01 2-9
2.4 Screw in objectives
• Remove dust caps (2-7/1) from the respective
openings in the nosepiece.
• Remove objectives (2-7/2) from the case and
screw them in the nosepiece (2-7/3), starting
with position 1 (see engraved number), in
increasing order of magnification factors. Make
sure that the objective is correctly and securely
locked.
☞
Make sure to use the dust
protection caps on those nosepiece
eyes which are not required.
Fig. 2-7 Screw in objectives
