Description of the device
000000-1520-928_GA_EN_021013
Description of the device
1
Optical measuring head
2
LCD touch screen (swivel-mounted)
3
On/Off button
4
Stylus (pointer)
Fig. 6 i.Profiler
® plus
, view from the operator side
Fig. 6 and Fig. 7 show the i.Profiler
® plus
from the operator and patient side.
The measuring head is inclined for functional reasons; this is not a defect.
