Connecting the printer to the i.Profiler
® plus
directly
(peer-to-peer)
• Connect the network printer or printer server with the i.Profiler
® plus
using
a crossover cable or a standard cable with a crossover adapter.
• Switch on the i.Profiler
® plus
and the printer or printer server.
• Configure the network printer or printer server with the aid of the user
manual provided with the device as follows:
IP address: 192.168.103.6, if using the right network connection
and 192.168.100.6, if using the left network
connection of the i.Profiler
® plus
, see page 22
(1, Fig. 9).
Subnet mask: 255.255.255.0
Standard gateway: 0.0.0.0
• In the Settings - Maintenance window (see Software description of the
i.Profiler
® plus
), select the Printer configuration option (administrator
privileges required). The Message dialog will open.
Confirm with Yes. The Printer Setup dialog for configuring the printer
appears.
• Press the Add New Printer button. The Printer Configuration dialog
appears. Follow the prompts appearing on the screen.
• Enter the IP address which has been set on the network printer or printer
server.
• Press the Test button. When the connection is successful, a green check
mark will appear.
• Confirm the selection with Finished. The printer appears in the list of the
Printer Setup dialog.
• Press the Properties button. Ensure that the Portrait print format is set.
• Press the Print Testpage button. A test page will now be printed to
confirm that the printer has been installed successfully.
• Press the Close button, in order to close the Printer Setup dialog. The
device will restart.
