Installation of the NAS device
Connecting the NAS directly to the i.Profiler
® plus
(peer-to-peer)
When connecting the NAS device directly (peer to peer) to the i.Profiler
® plus
the left-hand network port must be used.
• With the i.Profiler
® plus
and NAS device switched off connect the NAS
device using a so-called crossover cable directly to the i.Profiler
® plus
.
Detailed instructions on how to install the NAS device are provided in the
manual accompanying the NAS device.

Observe the safety precautions and requirements regarding cable
type and length.
• Switch the NAS device on and wait until initialization has been completed
before switching on the i.Profiler
® plus
. A light at the front of the NAS
device often indicates by a change of color that initialization has been
completed. For more detailed instructions see the manufacturer's
operating manual.
Installation of the Carl Zeiss Meditec (CZM) NAS device
• Switch the i.Profiler
® plus
on. After the start, quit the i.Profiler
® plus
software by pressing the Close Application button in the Shut Down
window+ and switch to the Microsoft Windows desktop (administrator
rights required). The LAN connection may be indicated in the task bar
bottom right when the NAS device is connected. Ignore this message for
the time being.
• Double-click on the Initialize CZM NAS Mapping program icon on the
Microsoft Windows desktop to connect the CZM-NAS device with the
drive letter N:\.
• Double-click on the Save Configurations program icon on the Microsoft
Windows desktop to save the configuration. The device will restart.
