54
Safety, Installation and Operations Manual – Translation of original instructions
9. Screw the inner top plug (II) onto the oil sump.
3700
M12N 4100
M13N 6100
M15N 6500
M17N 14700
13100
7. Screw on the inner bottom plug (II) of the oil sump.
8. Fill the mechanical seal sump with lubricating oil.
6. Place the vessel containing the oil on a horizontal surface and let it stand for a few minutes to allow any water in it to settle to the bottom:
• Oil clean and free from water: the mechanical seal is in good condition and new oil can be placed in the system.
• Oil with a very little water: this may be due to bedding-in of the mechanical seal during the initial operating hours, creating a negligible amount
of water.
• Oil containing water and dirt; the mechanical seal must be inspected and replaced with a new one. The replacement must be made by an
authorised Service Centre;
M12N
M13N
M15N
M17N
2x 3/8” DIN 906
EN
