10-6 Brake Maintenance Procedures
Maintenance and Safety
10
Brake Bleeding Procedure (Rear)
WARNING! Only use new brake fluid from and
airtight container. Fluid from open containers or
fluid previously used in the system will have
absorbed moisture, which will adversely affect
performance and must not be used.
WARNING! Brake fluid is highly toxic; keep
containers sealed and out of the reach of
children. If accidental consumption of brake fluid
is suspected, seek medical attention
immediately. If the brake fluid comes into
contact with the skin or eyes, rinse immediately
with plenty of water.
CAUTION: Brake fluid can damage plastic, as
well as painted and coated surfaces. Handle with
care and wipe up spills and wash the surfaces
immediately.
Tools Required:
9mm hex wrench
Vacuum bleeder
Fluid Required:
DOT4 Brake Fluid
Bleeding
1. Fill the rear master cylinder brake fluid
reservoir with DOT4 brake fluid. Keep the
reservoir full during this procedure.
CAUTION: Do not allow air to enter the
system during the bleeding procedure, or
the procedure will need to be repeated.
2. Open the rear caliper bleed screw (9mm).
3. Slowly press the brake lever down and hold it
until brake fluid flows out of the bleeder and
most of the air is gone. Tighten the bleeder
screw while holding the brake lever down.
4. Repeat this sequence until all the air is out of
the system and the lever is firm.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Zero SR/S and is the answer not in the manual?

Zero SR/S Specifications

General IconGeneral
CategoryMotorcycle
Peak Power110 hp (82 kW)
Continuous Power54 hp (40 kW)
Torque140 ft-lb (190 Nm)
Range (City)161 miles (259 km)
Range (with Power Tank)200 miles (322 km)
Top Speed (Max)124 mph (200 km/h)
Top Speed (Sustained)110 mph (177 km/h)
Front Tire120/70 ZR17
Rear Tire180/55 ZR17
MotorZ-Force 75-10
BatteryZF14.4 Lithium-ion
Range (Highway)82 miles (132 km) at 70 mph
Seat Height787 mm (30.9 in)
Wheelbase1, 450 mm (57.1 in)
Front SuspensionShowa 41 mm
Rear SuspensionShowa 40mm piston, piggy-back reservoir shock
Front BrakeDual J-Juan asymmetric piston calipers, 320 x 5 mm discs
Rear BrakeJ-Juan single piston floating caliper with 240mm disc
ABSBosch Gen 9
Charging Time (Standard)4.5 hours
